Brand |
KF |
|
Finish/Coating |
Tinned |
|
Base Materials |
Copper |
|
Insulation Material |
N/A |
|
Brazed |
Seam |
|
Wire/Cable Type |
Regular Wire |
|
Color Code |
Standard |
|
MOQ |
1000Pcs/item |
|
Payment Terms |
Based on orders |
|
Delivery |
FOB/CIF/DDP |
| Spec (American AWG) | 16 | 14 | 12 | 10 | 8 | 6 | 4 | 2 | 1/0 | 2/0 | 3/0 | 4/0 | 250/300MCM | 300/350MCM | 400MCM | 500MCM | 600/750MCM | 800/1000MCM | 1000/1250MCM |
| Spec (JIS AWG) | 1.5 | 2.5 | 4 | 6 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 | 185 | 240 | 300 | 400 | ||
| Spec (DIN AWG) | |||||||||||||||||||
| Spec (GB mm2) | |||||||||||||||||||
| Max Current | 18 | 30 | 35 | 50 | 70 | 95 | 125 | 170 | 230 | 265 | 310 | 360 | 445 | 505 | 545 | 620 | 785 | 935 | 1065 |
You can tick the products you need and communicate with us in the message board.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 16 | KFL1T10 | 16 AWG Copper Tubular Lugs (T) T1.5-4 | T1.5-4 | #8 | 0.169 | 0.343 | 0.748 | 0.157 | 0.094 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFL1T11 | 16 AWG Copper Tubular Lugs (T) T1.5-5 | T1.5-5 | #10 | 0.209 | 0.343 | 0.748 | 0.157 | 0.094 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFL1T12 | 16 AWG Copper Tubular Lugs (T) T1.5-6 | T1.5-6 | 1/4" | 0.252 | 0.394 | 0.787 | 0.157 | 0.094 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T20 | 14 AWG Copper Tubular Lugs (T) T2.5-4 | T2.5-4 | #8 | 0.169 | 0.343 | 0.748 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T21 | 14 AWG Copper Tubular Lugs (T) T2.5-5 | T2.5-5 | #10 | 0.209 | 0.343 | 0.748 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T22 | 14 AWG Copper Tubular Lugs (T) T2.5-6 | T2.5-6 | 1/4" | 0.252 | 0.406 | 0.827 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T23 | 14 AWG Copper Tubular Lugs (T) T2.5-8 | T2.5-8 | 5/16" | 0.327 | 0.472 | 0.906 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T30 | 12 AWG Copper Tubular Lugs (T) T4-4 | T4-4 | #8 | 0.169 | 0.343 | 0.846 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T31 | 12 AWG Copper Tubular Lugs (T) T4-5 | T4-5 | #10 | 0.209 | 0.343 | 0.846 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T32 | 12 AWG Copper Tubular Lugs (T) T4-6 | T4-6 | 1/4" | 0.252 | 0.406 | 0.925 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T33 | 12 AWG Copper Tubular Lugs (T) T4-8 | T4-8 | 5/16" | 0.327 | 0.492 | 1.122 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 10 | KFL1T40 | 10 AWG Copper Tubular Lugs (T) T6-4 | T6-4 | #8 | 0.169 | 0.406 | 1.024 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T41 | 10 AWG Copper Tubular Lugs (T) T6-5 | T6-5 | #10 | 0.209 | 0.406 | 1.024 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T42 | 10 AWG Copper Tubular Lugs (T) T6-6 | T6-6 | 1/4" | 0.252 | 0.406 | 1.024 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T43 | 10 AWG Copper Tubular Lugs (T) T6-8 | T6-7 | 5/16" | 0.327 | 0.547 | 1.142 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T44 | 10 AWG Copper Tubular Lugs (T) T6-10 | T6-10 | 3/8" | 0.413 | 0.547 | 1.142 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T50 | 8 AWG Copper Tubular Lugs (T) T10-4 | T10-4 | #8 | 0.169 | 0.469 | 1.083 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T51 | 8 AWG Copper Tubular Lugs (T) T10-5 | T10-5 | #10 | 0.209 | 0.469 | 1.083 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T52 | 8 AWG Copper Tubular Lugs (T) T10-6 | T10-6 | 1/4" | 0.252 | 0.469 | 1.083 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T53 | 8 AWG Copper Tubular Lugs (T) T10-8 | T10-8 | 5/16" | 0.327 | 0.531 | 1.201 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T54 | 8 AWG Copper Tubular Lugs (T) T10-10 | T10-10 | 3/8" | 0.413 | 0.591 | 1.201 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T55 | 8 AWG Copper Tubular Lugs (T) T10-12 | T10-12 | 1/2" | 0.520 | 0.669 | 1.339 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFL1T60 | 6 AWG Copper Tubular Lugs (T) T16-5 | T16-5 | #10 | 0.209 | 0.472 | 1.083 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T61 | 6 AWG Copper Tubular Lugs (T) T16-6 | T16-6 | 1/4" | 0.252 | 0.472 | 1.083 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T62 | 6 AWG Copper Tubular Lugs (T) T16-8 | T16-8 | 5/16" | 0.327 | 0.531 | 0.827 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T63 | 6 AWG Copper Tubular Lugs (T) T16-10 | T16-10 | 3/8" | 0.413 | 0.630 | 1.260 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T64 | 6 AWG Copper Tubular Lugs (T) T16-12 | T16-12 | 1/2" | 0.520 | 0.669 | 1.476 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 4 | KFL1T70 | 4 AWG Copper Tubular Lugs (T) T25-6 | T25-6 | 1/4" | 0.252 | 0.551 | 1.339 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFL1T71 | 4 AWG Copper Tubular Lugs (T) T25-8 | T25-8 | 5/16" | 0.327 | 0.551 | 1.339 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFL1T72 | 4 AWG Copper Tubular Lugs (T) T25-10 | T25-10 | 3/8" | 0.413 | 0.630 | 1.457 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFL1T73 | 4 AWG Copper Tubular Lugs (T) T25-12 | T25-12 | 1/2" | 0.520 | 0.709 | 1.575 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 2 | KFL1T80 | 2 AWG Copper Tubular Lugs (T) T35-6 | T35-6 | 1/4" | 0.252 | 0.650 | 1.535 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T81 | 2 AWG Copper Tubular Lugs (T) T35-8 | T35-8 | 5/16" | 0.327 | 0.650 | 1.535 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T82 | 2 AWG Copper Tubular Lugs (T) T35-10 | T35-10 | 3/8" | 0.413 | 0.650 | 1.693 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T83 | 2 AWG Copper Tubular Lugs (T) T35-12 | T35-12 | 1/2" | 0.520 | 0.709 | 1.693 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T84 | 2 AWG Copper Tubular Lugs (T) T35-14 | T35-14 | 9/16" | 0.571 | 0.787 | 1.890 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T85 | 2 AWG Copper Tubular Lugs (T) T35-16 | T35-16 | 5/8" | 0.650 | 0.906 | 1.890 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T90 | 1 AWG Copper Tubular Lugs (T) T40-6 | T40-6 | 1/4" | 0.252 | 0.669 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T91 | 1 AWG Copper Tubular Lugs (T) T40-8 | T40-8 | 5/16" | 0.327 | 0.669 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T92 | 1 AWG Copper Tubular Lugs (T) T40-10 | T40-10 | 3/8" | 0.413 | 0.669 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T93 | 1 AWG Copper Tubular Lugs (T) T40-12 | T40-12 | 1/2" | 0.520 | 0.709 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFL1TA0 | 1/0 AWG Copper Tubular Lugs (T) T50-6 | T50-6 | 1/4" | 0.252 | 0.709 | 1.772 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA1 | 1/0 AWG Copper Tubular Lugs (T) T50-8 | T50-8 | 5/16" | 0.327 | 0.709 | 1.772 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA2 | 1/0 AWG Copper Tubular Lugs (T) T50-10 | T50-10 | 3/8" | 0.413 | 0.709 | 1.929 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA3 | 1/0 AWG Copper Tubular Lugs (T) T50-12 | T50-12 | 1/2" | 0.520 | 0.709 | 1.929 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA4 | 1/0 AWG Copper Tubular Lugs (T) T50-14 | T50-14 | 9/16" | 0.571 | 0.866 | 2.126 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA5 | 1/0 AWG Copper Tubular Lugs (T) T50-16 | T50-16 | 5/8" | 0.650 | 0.984 | 2.441 | 0.551 | 0.374 | 0.906 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA6 | 1/0 AWG Copper Tubular Lugs (T) T50-20 | T50-20 | 3/8" | 0.827 | 1.181 | 2.677 | 0.551 | 0.374 | 0.906 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB0 | 2/0 AWG Copper Tubular Lugs (T) T70-8 | T70-8 | 5/16" | 0.327 | 0.866 | 1.874 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB1 | 2/0 AWG Copper Tubular Lugs (T) T70-10 | T70-10 | 3/8" | 0.413 | 0.866 | 2.031 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB2 | 2/0 AWG Copper Tubular Lugs (T) T70-12 | T70-12 | 1/2" | 0.520 | 0.866 | 2.031 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB3 | 2/0 AWG Copper Tubular Lugs (T) T70-14 | T70-14 | 9/16" | 0.571 | 0.866 | 2.465 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB4 | 2/0 AWG Copper Tubular Lugs (T) T70-16 | T70-16 | 5/8" | 0.650 | 0.866 | 2.465 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB5 | 2/0 AWG Copper Tubular Lugs (T) T70-20 | T70-20 | 3/4" | 0.827 | 1.181 | 2.465 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFL1TC0 | 3/0 AWG Copper Tubular Lugs (T) T95-8 | T95-8 | 5/16" | 0.327 | 0.984 | 2.197 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC1 | 3/0 AWG Copper Tubular Lugs (T) T95-10 | T95-10 | 3/8" | 0.413 | 0.984 | 2.197 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC2 | 3/0 AWG Copper Tubular Lugs (T) T95-12 | T95-12 | 1/2" | 0.520 | 0.984 | 2.197 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC3 | 3/0 AWG Copper Tubular Lugs (T) T95-14 | T95-14 | 9/16" | 0.571 | 0.984 | 2.630 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC4 | 3/0 AWG Copper Tubular Lugs (T) T95-16 | T95-16 | 5/8" | 0.650 | 0.984 | 2.630 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC5 | 3/0 AWG Copper Tubular Lugs (T) T95-20 | T95-20 | 3/4" | 0.827 | 1.102 | 2.630 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFL1TD0 | 4/0 AWG Copper Tubular Lugs (T) T120-10 | T120-10 | 3/8" | 0.413 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD1 | 4/0 AWG Copper Tubular Lugs (T) T120-12 | T120-12 | 1/2" | 0.520 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD2 | 4/0 AWG Copper Tubular Lugs (T) T120-14 | T120-14 | 9/16" | 0.571 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD3 | 4/0 AWG Copper Tubular Lugs (T) T120-16 | T120-16 | 5/8" | 0.650 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD4 | 4/0 AWG Copper Tubular Lugs (T) T120-20 | T120-20 | 3/4" | 0.827 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFL1TE0 | 250/300MCM AWG Copper Tubular Lugs (T) T150-10 | T150-10 | 3/8" | 0.413 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE1 | 250/300MCM AWG Copper Tubular Lugs (T) T150-12 | T150-12 | 1/2" | 0.520 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE2 | 250/300MCM AWG Copper Tubular Lugs (T) T150-14 | T150-14 | 9/16" | 0.571 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE3 | 250/300MCM AWG Copper Tubular Lugs (T) T150-16 | T150-16 | 5/8" | 0.650 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE4 | 250/300MCM AWG Copper Tubular Lugs (T) T150-20 | T150-20 | 3/4" | 0.827 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF0 | 300/350MCM AWG Copper Tubular Lugs (T) T185-10 | T185-10 | 3/8" | 0.413 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF1 | 300/350MCM AWG Copper Tubular Lugs (T) T185-12 | T185-12 | 1/2" | 0.520 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF2 | 300/350MCM AWG Copper Tubular Lugs (T) T185-14 | T185-14 | 9/16" | 0.571 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF3 | 300/350MCM AWG Copper Tubular Lugs (T) T185-16 | T185-16 | 5/8" | 0.650 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF4 | 300/350MCM AWG Copper Tubular Lugs (T) T185-20 | T185-20 | 3/4" | 0.827 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG0 | 400MCM AWG Copper Tubular Lugs (T) T240-10 | T240-10 | 3/8" | 0.413 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG1 | 400MCM AWG Copper Tubular Lugs (T) T240-12 | T240-12 | 1/2" | 0.520 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG2 | 400MCM AWG Copper Tubular Lugs (T) T240-14 | T240-14 | 9/16" | 0.571 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG3 | 400MCM AWG Copper Tubular Lugs (T) T240-16 | T240-16 | 5/8" | 0.650 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG4 | 400MCM AWG Copper Tubular Lugs (T) T240-20 | T240-20 | 3/4" | 0.827 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFL1TH0 | 500MCM AWG Copper Tubular Lugs (T) T300-10 | T300-10 | 3/8" | 0.413 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH1 | 500MCM AWG Copper Tubular Lugs (T) T300-12 | T300-12 | 1/2" | 0.520 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH2 | 500MCM AWG Copper Tubular Lugs (T) T300-14 | T300-14 | 9/16" | 0.571 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH3 | 500MCM AWG Copper Tubular Lugs (T) T300-16 | T300-16 | 5/8" | 0.650 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH4 | 500MCM AWG Copper Tubular Lugs (T) T300-20 | T300-20 | 3/4" | 0.827 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI0 | 600/750MCM AWG Copper Tubular Lugs (T) T400-10 | T400-10 | 3/8" | 0.413 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI1 | 600/750MCM AWG Copper Tubular Lugs (T) T400-12 | T400-12 | 1/2" | 0.520 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI2 | 600/750MCM AWG Copper Tubular Lugs (T) T400-14 | T400-14 | 9/16" | 0.571 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI3 | 600/750MCM AWG Copper Tubular Lugs (T) T400-16 | T400-16 | 5/8" | 0.650 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI4 | 600/750MCM AWG Copper Tubular Lugs (T) T400-20 | T400-20 | 3/4" | 0.827 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ0 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-10 | T500-10 | 3/8" | 0.413 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ1 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-12 | T500-12 | 1/2" | 0.520 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ2 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-14 | T500-14 | 9/16" | 0.571 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ3 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-16 | T500-16 | 5/8" | 0.650 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ4 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-20 | T500-20 | 3/4" | 0.827 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK0 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-10 | T630-10 | 3/8" | 0.413 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK1 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-12 | T630-12 | 1/2" | 0.520 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK2 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-14 | T630-14 | 9/16" | 0.571 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK3 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-16 | T630-16 | 5/8" | 0.650 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK4 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-20 | T630-20 | 3/4" | 0.827 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 1.5mm² | KFL1T10 | 16 AWG Copper Tubular Lugs (T) T1.5-4 | T1.5-4 | 4 | 4.3 | 8.7 | 19.0 | 4.0 | 2.4 | 7.00 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFL1T11 | 16 AWG Copper Tubular Lugs (T) T1.5-5 | T1.5-5 | 5 | 5.3 | 8.7 | 19.0 | 4.0 | 2.4 | 7.00 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFL1T12 | 16 AWG Copper Tubular Lugs (T) T1.5-6 | T1.5-6 | 6 | 6.4 | 10.0 | 20.0 | 4.0 | 2.4 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T20 | 14 AWG Copper Tubular Lugs (T) T2.5-4 | T2.5-4 | 4 | 4.3 | 8.7 | 19.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T21 | 14 AWG Copper Tubular Lugs (T) T2.5-5 | T2.5-5 | 5 | 5.3 | 8.7 | 19.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T22 | 14 AWG Copper Tubular Lugs (T) T2.5-6 | T2.5-6 | 6 | 6.4 | 10.3 | 21.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T23 | 14 AWG Copper Tubular Lugs (T) T2.5-8 | T2.5-8 | 8 | 8.3 | 12.0 | 23.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T30 | 12 AWG Copper Tubular Lugs (T) T4-4 | T4-4 | 4 | 4.3 | 8.7 | 21.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T31 | 12 AWG Copper Tubular Lugs (T) T4-5 | T4-5 | 5 | 5.3 | 8.7 | 21.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T32 | 12 AWG Copper Tubular Lugs (T) T4-6 | T4-6 | 6 | 6.4 | 10.3 | 23.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T33 | 12 AWG Copper Tubular Lugs (T) T4-8 | T4-8 | 8 | 8.3 | 12.5 | 28.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 6.0mm² | KFL1T40 | 10 AWG Copper Tubular Lugs (T) T6-4 | T6-4 | 4 | 4.3 | 10.3 | 26.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T41 | 10 AWG Copper Tubular Lugs (T) T6-5 | T6-5 | 5 | 5.3 | 10.3 | 26.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T42 | 10 AWG Copper Tubular Lugs (T) T6-6 | T6-6 | 6 | 6.4 | 10.3 | 26.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T43 | 10 AWG Copper Tubular Lugs (T) T6-8 | T6-7 | 7 | 8.3 | 13.9 | 29.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T44 | 10 AWG Copper Tubular Lugs (T) T6-10 | T6-10 | 10 | 10.5 | 13.9 | 29.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T50 | 8 AWG Copper Tubular Lugs (T) T10-4 | T10-4 | 4 | 4.3 | 11.9 | 27.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T51 | 8 AWG Copper Tubular Lugs (T) T10-5 | T10-5 | 5 | 5.3 | 11.9 | 27.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T52 | 8 AWG Copper Tubular Lugs (T) T10-6 | T10-6 | 6 | 6.4 | 11.9 | 27.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T53 | 8 AWG Copper Tubular Lugs (T) T10-8 | T10-8 | 8 | 8.3 | 13.5 | 30.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T54 | 8 AWG Copper Tubular Lugs (T) T10-10 | T10-10 | 10 | 10.5 | 15.0 | 30.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T55 | 8 AWG Copper Tubular Lugs (T) T10-12 | T10-12 | 12 | 13.2 | 17.0 | 34.0 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 16.0mm² | KFL1T60 | 6 AWG Copper Tubular Lugs (T) T16-5 | T16-5 | 5 | 5.3 | 12.0 | 27.5 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T61 | 6 AWG Copper Tubular Lugs (T) T16-6 | T16-6 | 6 | 6.4 | 12.0 | 27.5 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T62 | 6 AWG Copper Tubular Lugs (T) T16-8 | T16-8 | 8 | 8.3 | 13.5 | 21.0 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T63 | 6 AWG Copper Tubular Lugs (T) T16-10 | T16-10 | 10 | 10.5 | 16.0 | 32.0 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T64 | 6 AWG Copper Tubular Lugs (T) T16-12 | T16-12 | 12 | 13.2 | 17.0 | 37.5 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 25.0mm | KFL1T70 | 4 AWG Copper Tubular Lugs (T) T25-6 | T25-6 | 6 | 6.4 | 14.0 | 34.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 25.0mm | KFL1T71 | 4 AWG Copper Tubular Lugs (T) T25-8 | T25-8 | 8 | 8.3 | 14.0 | 34.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 25.0mm | KFL1T72 | 4 AWG Copper Tubular Lugs (T) T25-10 | T25-10 | 10 | 10.5 | 16.0 | 37.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 25.0mm | KFL1T73 | 4 AWG Copper Tubular Lugs (T) T25-12 | T25-12 | 12 | 13.2 | 18.0 | 40.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 35mm² | KFL1T80 | 2 AWG Copper Tubular Lugs (T) T35-6 | T35-6 | 6 | 6.4 | 16.5 | 39.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T81 | 2 AWG Copper Tubular Lugs (T) T35-8 | T35-8 | 8 | 8.3 | 16.5 | 39.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T82 | 2 AWG Copper Tubular Lugs (T) T35-10 | T35-10 | 10 | 10.5 | 16.5 | 43.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T83 | 2 AWG Copper Tubular Lugs (T) T35-12 | T35-12 | 12 | 13.2 | 18.0 | 43.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T84 | 2 AWG Copper Tubular Lugs (T) T35-14 | T35-14 | 14 | 14.5 | 20.0 | 48.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T85 | 2 AWG Copper Tubular Lugs (T) T35-16 | T35-16 | 16 | 16.5 | 23.0 | 48.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T90 | 1 AWG Copper Tubular Lugs (T) T40-6 | T40-6 | 6 | 6.4 | 17.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T91 | 1 AWG Copper Tubular Lugs (T) T40-8 | T40-8 | 8 | 8.3 | 17.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T92 | 1 AWG Copper Tubular Lugs (T) T40-10 | T40-10 | 10 | 10.5 | 17.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T93 | 1 AWG Copper Tubular Lugs (T) T40-12 | T40-12 | 12 | 13.2 | 18.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 50mm² | KFL1TA0 | 1/0 AWG Copper Tubular Lugs (T) T50-6 | T50-6 | 6 | 6.4 | 18.0 | 45.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA1 | 1/0 AWG Copper Tubular Lugs (T) T50-8 | T50-8 | 8 | 8.3 | 18.0 | 45.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA2 | 1/0 AWG Copper Tubular Lugs (T) T50-10 | T50-10 | 10 | 10.5 | 18.0 | 49.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA3 | 1/0 AWG Copper Tubular Lugs (T) T50-12 | T50-12 | 12 | 13.2 | 18.0 | 49.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA4 | 1/0 AWG Copper Tubular Lugs (T) T50-14 | T50-14 | 14 | 14.5 | 22.0 | 54.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA5 | 1/0 AWG Copper Tubular Lugs (T) T50-16 | T50-16 | 16 | 16.5 | 25.0 | 62.0 | 14.0 | 9.5 | 23.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA6 | 1/0 AWG Copper Tubular Lugs (T) T50-20 | T50-20 | 20 | 21.0 | 30.0 | 68.0 | 14.0 | 9.5 | 23.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB0 | 2/0 AWG Copper Tubular Lugs (T) T70-8 | T70-8 | 8 | 8.3 | 22.0 | 47.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB1 | 2/0 AWG Copper Tubular Lugs (T) T70-10 | T70-10 | 10 | 10.5 | 22.0 | 51.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB2 | 2/0 AWG Copper Tubular Lugs (T) T70-12 | T70-12 | 12 | 13.2 | 22.0 | 51.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB3 | 2/0 AWG Copper Tubular Lugs (T) T70-14 | T70-14 | 14 | 14.5 | 22.0 | 62.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB4 | 2/0 AWG Copper Tubular Lugs (T) T70-16 | T70-16 | 16 | 16.5 | 22.0 | 62.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB5 | 2/0 AWG Copper Tubular Lugs (T) T70-20 | T70-20 | 20 | 21.0 | 30.0 | 62.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 95mm² | KFL1TC0 | 3/0 AWG Copper Tubular Lugs (T) T95-8 | T95-8 | 8 | 8.3 | 25.0 | 55.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC1 | 3/0 AWG Copper Tubular Lugs (T) T95-10 | T95-10 | 10 | 10.5 | 25.0 | 55.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC2 | 3/0 AWG Copper Tubular Lugs (T) T95-12 | T95-12 | 12 | 13.2 | 25.0 | 55.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC3 | 3/0 AWG Copper Tubular Lugs (T) T95-14 | T95-14 | 14 | 14.5 | 25.0 | 66.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC4 | 3/0 AWG Copper Tubular Lugs (T) T95-16 | T95-16 | 16 | 16.5 | 25.0 | 66.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC5 | 3/0 AWG Copper Tubular Lugs (T) T95-20 | T95-20 | 20 | 21.0 | 28.0 | 66.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 120mm² | KFL1TD0 | 4/0 AWG Copper Tubular Lugs (T) T120-10 | T120-10 | 10 | 10.5 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD1 | 4/0 AWG Copper Tubular Lugs (T) T120-12 | T120-12 | 12 | 13.2 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD2 | 4/0 AWG Copper Tubular Lugs (T) T120-14 | T120-14 | 14 | 14.5 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD3 | 4/0 AWG Copper Tubular Lugs (T) T120-16 | T120-16 | 16 | 16.5 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD4 | 4/0 AWG Copper Tubular Lugs (T) T120-20 | T120-20 | 20 | 21.0 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 150mm² | KFL1TE0 | 250/300MCM AWG Copper Tubular Lugs (T) T150-10 | T150-10 | 10 | 10.5 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE1 | 250/300MCM AWG Copper Tubular Lugs (T) T150-12 | T150-12 | 12 | 13.2 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE2 | 250/300MCM AWG Copper Tubular Lugs (T) T150-14 | T150-14 | 14 | 14.5 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE3 | 250/300MCM AWG Copper Tubular Lugs (T) T150-16 | T150-16 | 16 | 16.5 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE4 | 250/300MCM AWG Copper Tubular Lugs (T) T150-20 | T150-20 | 20 | 21.0 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF0 | 300/350MCM AWG Copper Tubular Lugs (T) T185-10 | T185-10 | 10 | 10.5 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF1 | 300/350MCM AWG Copper Tubular Lugs (T) T185-12 | T185-12 | 12 | 13.2 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF2 | 300/350MCM AWG Copper Tubular Lugs (T) T185-14 | T185-14 | 14 | 14.5 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF3 | 300/350MCM AWG Copper Tubular Lugs (T) T185-16 | T185-16 | 16 | 16.5 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF4 | 300/350MCM AWG Copper Tubular Lugs (T) T185-20 | T185-20 | 20 | 21.0 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG0 | 400MCM AWG Copper Tubular Lugs (T) T240-10 | T240-10 | 10 | 10.5 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG1 | 400MCM AWG Copper Tubular Lugs (T) T240-12 | T240-12 | 12 | 13.2 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG2 | 400MCM AWG Copper Tubular Lugs (T) T240-14 | T240-14 | 14 | 14.5 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG3 | 400MCM AWG Copper Tubular Lugs (T) T240-16 | T240-16 | 16 | 16.5 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG4 | 400MCM AWG Copper Tubular Lugs (T) T240-20 | T240-20 | 20 | 21.0 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 300mm² | KFL1TH0 | 500MCM AWG Copper Tubular Lugs (T) T300-10 | T300-10 | 10 | 10.5 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH1 | 500MCM AWG Copper Tubular Lugs (T) T300-12 | T300-12 | 12 | 13.2 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH2 | 500MCM AWG Copper Tubular Lugs (T) T300-14 | T300-14 | 14 | 14.5 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH3 | 500MCM AWG Copper Tubular Lugs (T) T300-16 | T300-16 | 16 | 16.5 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH4 | 500MCM AWG Copper Tubular Lugs (T) T300-20 | T300-20 | 20 | 21.0 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI0 | 600/750MCM AWG Copper Tubular Lugs (T) T400-10 | T400-10 | 10 | 10.5 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI1 | 600/750MCM AWG Copper Tubular Lugs (T) T400-12 | T400-12 | 12 | 13.2 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI2 | 600/750MCM AWG Copper Tubular Lugs (T) T400-14 | T400-14 | 14 | 14.5 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI3 | 600/750MCM AWG Copper Tubular Lugs (T) T400-16 | T400-16 | 16 | 16.5 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI4 | 600/750MCM AWG Copper Tubular Lugs (T) T400-20 | T400-20 | 20 | 21.0 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ0 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-10 | T500-10 | 10 | 10.5 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ1 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-12 | T500-12 | 12 | 13.2 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ2 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-14 | T500-14 | 14 | 14.5 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ3 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-16 | T500-16 | 16 | 16.5 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ4 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-20 | T500-20 | 20 | 21.0 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK0 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-10 | T630-10 | 10 | 10.5 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK1 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-12 | T630-12 | 12 | 13.2 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK2 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-14 | T630-14 | 14 | 14.5 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK3 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-16 | T630-16 | 16 | 16.5 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK4 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-20 | T630-20 | 20 | 21.0 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
Want to get a sample? Please fill in the form, leave your contact information and parameter information.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 16 | KFL1T10 | 16 AWG Copper Tubular Lugs (T) T1.5-4 | T1.5-4 | #8 | 0.169 | 0.343 | 0.748 | 0.157 | 0.094 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFL1T11 | 16 AWG Copper Tubular Lugs (T) T1.5-5 | T1.5-5 | #10 | 0.209 | 0.343 | 0.748 | 0.157 | 0.094 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFL1T12 | 16 AWG Copper Tubular Lugs (T) T1.5-6 | T1.5-6 | 1/4" | 0.252 | 0.394 | 0.787 | 0.157 | 0.094 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T20 | 14 AWG Copper Tubular Lugs (T) T2.5-4 | T2.5-4 | #8 | 0.169 | 0.343 | 0.748 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T21 | 14 AWG Copper Tubular Lugs (T) T2.5-5 | T2.5-5 | #10 | 0.209 | 0.343 | 0.748 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T22 | 14 AWG Copper Tubular Lugs (T) T2.5-6 | T2.5-6 | 1/4" | 0.252 | 0.406 | 0.827 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFL1T23 | 14 AWG Copper Tubular Lugs (T) T2.5-8 | T2.5-8 | 5/16" | 0.327 | 0.472 | 0.906 | 0.169 | 0.106 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T30 | 12 AWG Copper Tubular Lugs (T) T4-4 | T4-4 | #8 | 0.169 | 0.343 | 0.846 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T31 | 12 AWG Copper Tubular Lugs (T) T4-5 | T4-5 | #10 | 0.209 | 0.343 | 0.846 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T32 | 12 AWG Copper Tubular Lugs (T) T4-6 | T4-6 | 1/4" | 0.252 | 0.406 | 0.925 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFL1T33 | 12 AWG Copper Tubular Lugs (T) T4-8 | T4-8 | 5/16" | 0.327 | 0.492 | 1.122 | 0.189 | 0.122 | 0.374 | IZUMI 5N18 | 1000 |
| A.W.G. 10 | KFL1T40 | 10 AWG Copper Tubular Lugs (T) T6-4 | T6-4 | #8 | 0.169 | 0.406 | 1.024 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T41 | 10 AWG Copper Tubular Lugs (T) T6-5 | T6-5 | #10 | 0.209 | 0.406 | 1.024 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T42 | 10 AWG Copper Tubular Lugs (T) T6-6 | T6-6 | 1/4" | 0.252 | 0.406 | 1.024 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T43 | 10 AWG Copper Tubular Lugs (T) T6-8 | T6-7 | 5/16" | 0.327 | 0.547 | 1.142 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFL1T44 | 10 AWG Copper Tubular Lugs (T) T6-10 | T6-10 | 3/8" | 0.413 | 0.547 | 1.142 | 0.217 | 0.150 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T50 | 8 AWG Copper Tubular Lugs (T) T10-4 | T10-4 | #8 | 0.169 | 0.469 | 1.083 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T51 | 8 AWG Copper Tubular Lugs (T) T10-5 | T10-5 | #10 | 0.209 | 0.469 | 1.083 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T52 | 8 AWG Copper Tubular Lugs (T) T10-6 | T10-6 | 1/4" | 0.252 | 0.469 | 1.083 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T53 | 8 AWG Copper Tubular Lugs (T) T10-8 | T10-8 | 5/16" | 0.327 | 0.531 | 1.201 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T54 | 8 AWG Copper Tubular Lugs (T) T10-10 | T10-10 | 3/8" | 0.413 | 0.591 | 1.201 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFL1T55 | 8 AWG Copper Tubular Lugs (T) T10-12 | T10-12 | 1/2" | 0.520 | 0.669 | 1.339 | 0.272 | 0.185 | 0.453 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFL1T60 | 6 AWG Copper Tubular Lugs (T) T16-5 | T16-5 | #10 | 0.209 | 0.472 | 1.083 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T61 | 6 AWG Copper Tubular Lugs (T) T16-6 | T16-6 | 1/4" | 0.252 | 0.472 | 1.083 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T62 | 6 AWG Copper Tubular Lugs (T) T16-8 | T16-8 | 5/16" | 0.327 | 0.531 | 0.827 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T63 | 6 AWG Copper Tubular Lugs (T) T16-10 | T16-10 | 3/8" | 0.413 | 0.630 | 1.260 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFL1T64 | 6 AWG Copper Tubular Lugs (T) T16-12 | T16-12 | 1/2" | 0.520 | 0.669 | 1.476 | 0.307 | 0.220 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 4 | KFL1T70 | 4 AWG Copper Tubular Lugs (T) T25-6 | T25-6 | 1/4" | 0.252 | 0.551 | 1.339 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFL1T71 | 4 AWG Copper Tubular Lugs (T) T25-8 | T25-8 | 5/16" | 0.327 | 0.551 | 1.339 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFL1T72 | 4 AWG Copper Tubular Lugs (T) T25-10 | T25-10 | 3/8" | 0.413 | 0.630 | 1.457 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFL1T73 | 4 AWG Copper Tubular Lugs (T) T25-12 | T25-12 | 1/2" | 0.520 | 0.709 | 1.575 | 0.374 | 0.280 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 2 | KFL1T80 | 2 AWG Copper Tubular Lugs (T) T35-6 | T35-6 | 1/4" | 0.252 | 0.650 | 1.535 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T81 | 2 AWG Copper Tubular Lugs (T) T35-8 | T35-8 | 5/16" | 0.327 | 0.650 | 1.535 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T82 | 2 AWG Copper Tubular Lugs (T) T35-10 | T35-10 | 3/8" | 0.413 | 0.650 | 1.693 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T83 | 2 AWG Copper Tubular Lugs (T) T35-12 | T35-12 | 1/2" | 0.520 | 0.709 | 1.693 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T84 | 2 AWG Copper Tubular Lugs (T) T35-14 | T35-14 | 9/16" | 0.571 | 0.787 | 1.890 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 2 | KFL1T85 | 2 AWG Copper Tubular Lugs (T) T35-16 | T35-16 | 5/8" | 0.650 | 0.906 | 1.890 | 0.433 | 0.323 | 0.630 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T90 | 1 AWG Copper Tubular Lugs (T) T40-6 | T40-6 | 1/4" | 0.252 | 0.669 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T91 | 1 AWG Copper Tubular Lugs (T) T40-8 | T40-8 | 5/16" | 0.327 | 0.669 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T92 | 1 AWG Copper Tubular Lugs (T) T40-10 | T40-10 | 3/8" | 0.413 | 0.669 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1 | KFL1T93 | 1 AWG Copper Tubular Lugs (T) T40-12 | T40-12 | 1/2" | 0.520 | 0.709 | 1.732 | 0.441 | 0.354 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFL1TA0 | 1/0 AWG Copper Tubular Lugs (T) T50-6 | T50-6 | 1/4" | 0.252 | 0.709 | 1.772 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA1 | 1/0 AWG Copper Tubular Lugs (T) T50-8 | T50-8 | 5/16" | 0.327 | 0.709 | 1.772 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA2 | 1/0 AWG Copper Tubular Lugs (T) T50-10 | T50-10 | 3/8" | 0.413 | 0.709 | 1.929 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA3 | 1/0 AWG Copper Tubular Lugs (T) T50-12 | T50-12 | 1/2" | 0.520 | 0.709 | 1.929 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA4 | 1/0 AWG Copper Tubular Lugs (T) T50-14 | T50-14 | 9/16" | 0.571 | 0.866 | 2.126 | 0.492 | 0.374 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA5 | 1/0 AWG Copper Tubular Lugs (T) T50-16 | T50-16 | 5/8" | 0.650 | 0.984 | 2.441 | 0.551 | 0.374 | 0.906 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFL1TA6 | 1/0 AWG Copper Tubular Lugs (T) T50-20 | T50-20 | 3/8" | 0.827 | 1.181 | 2.677 | 0.551 | 0.374 | 0.906 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB0 | 2/0 AWG Copper Tubular Lugs (T) T70-8 | T70-8 | 5/16" | 0.327 | 0.866 | 1.874 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB1 | 2/0 AWG Copper Tubular Lugs (T) T70-10 | T70-10 | 3/8" | 0.413 | 0.866 | 2.031 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB2 | 2/0 AWG Copper Tubular Lugs (T) T70-12 | T70-12 | 1/2" | 0.520 | 0.866 | 2.031 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB3 | 2/0 AWG Copper Tubular Lugs (T) T70-14 | T70-14 | 9/16" | 0.571 | 0.866 | 2.465 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB4 | 2/0 AWG Copper Tubular Lugs (T) T70-16 | T70-16 | 5/8" | 0.650 | 0.866 | 2.465 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFL1TB5 | 2/0 AWG Copper Tubular Lugs (T) T70-20 | T70-20 | 3/4" | 0.827 | 1.181 | 2.465 | 0.591 | 0.453 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFL1TC0 | 3/0 AWG Copper Tubular Lugs (T) T95-8 | T95-8 | 5/16" | 0.327 | 0.984 | 2.197 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC1 | 3/0 AWG Copper Tubular Lugs (T) T95-10 | T95-10 | 3/8" | 0.413 | 0.984 | 2.197 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC2 | 3/0 AWG Copper Tubular Lugs (T) T95-12 | T95-12 | 1/2" | 0.520 | 0.984 | 2.197 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC3 | 3/0 AWG Copper Tubular Lugs (T) T95-14 | T95-14 | 9/16" | 0.571 | 0.984 | 2.630 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC4 | 3/0 AWG Copper Tubular Lugs (T) T95-16 | T95-16 | 5/8" | 0.650 | 0.984 | 2.630 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFL1TC5 | 3/0 AWG Copper Tubular Lugs (T) T95-20 | T95-20 | 3/4" | 0.827 | 1.102 | 2.630 | 0.669 | 0.531 | 0.866 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFL1TD0 | 4/0 AWG Copper Tubular Lugs (T) T120-10 | T120-10 | 3/8" | 0.413 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD1 | 4/0 AWG Copper Tubular Lugs (T) T120-12 | T120-12 | 1/2" | 0.520 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD2 | 4/0 AWG Copper Tubular Lugs (T) T120-14 | T120-14 | 9/16" | 0.571 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD3 | 4/0 AWG Copper Tubular Lugs (T) T120-16 | T120-16 | 5/8" | 0.650 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFL1TD4 | 4/0 AWG Copper Tubular Lugs (T) T120-20 | T120-20 | 3/4" | 0.827 | 1.142 | 2.815 | 0.787 | 0.614 | 1.063 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFL1TE0 | 250/300MCM AWG Copper Tubular Lugs (T) T150-10 | T150-10 | 3/8" | 0.413 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE1 | 250/300MCM AWG Copper Tubular Lugs (T) T150-12 | T150-12 | 1/2" | 0.520 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE2 | 250/300MCM AWG Copper Tubular Lugs (T) T150-14 | T150-14 | 9/16" | 0.571 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE3 | 250/300MCM AWG Copper Tubular Lugs (T) T150-16 | T150-16 | 5/8" | 0.650 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFL1TE4 | 250/300MCM AWG Copper Tubular Lugs (T) T150-20 | T150-20 | 3/4" | 0.827 | 1.205 | 3.071 | 0.827 | 0.650 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF0 | 300/350MCM AWG Copper Tubular Lugs (T) T185-10 | T185-10 | 3/8" | 0.413 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF1 | 300/350MCM AWG Copper Tubular Lugs (T) T185-12 | T185-12 | 1/2" | 0.520 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF2 | 300/350MCM AWG Copper Tubular Lugs (T) T185-14 | T185-14 | 9/16" | 0.571 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF3 | 300/350MCM AWG Copper Tubular Lugs (T) T185-16 | T185-16 | 5/8" | 0.650 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFL1TF4 | 300/350MCM AWG Copper Tubular Lugs (T) T185-20 | T185-20 | 3/4" | 0.827 | 1.339 | 3.307 | 0.929 | 0.724 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG0 | 400MCM AWG Copper Tubular Lugs (T) T240-10 | T240-10 | 3/8" | 0.413 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG1 | 400MCM AWG Copper Tubular Lugs (T) T240-12 | T240-12 | 1/2" | 0.520 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG2 | 400MCM AWG Copper Tubular Lugs (T) T240-14 | T240-14 | 9/16" | 0.571 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG3 | 400MCM AWG Copper Tubular Lugs (T) T240-16 | T240-16 | 5/8" | 0.650 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFL1TG4 | 400MCM AWG Copper Tubular Lugs (T) T240-20 | T240-20 | 3/4" | 0.827 | 1.516 | 3.543 | 1.039 | 0.835 | 1.457 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFL1TH0 | 500MCM AWG Copper Tubular Lugs (T) T300-10 | T300-10 | 3/8" | 0.413 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH1 | 500MCM AWG Copper Tubular Lugs (T) T300-12 | T300-12 | 1/2" | 0.520 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH2 | 500MCM AWG Copper Tubular Lugs (T) T300-14 | T300-14 | 9/16" | 0.571 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH3 | 500MCM AWG Copper Tubular Lugs (T) T300-16 | T300-16 | 5/8" | 0.650 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFL1TH4 | 500MCM AWG Copper Tubular Lugs (T) T300-20 | T300-20 | 3/4" | 0.827 | 1.654 | 3.780 | 1.126 | 0.921 | 1.575 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI0 | 600/750MCM AWG Copper Tubular Lugs (T) T400-10 | T400-10 | 3/8" | 0.413 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI1 | 600/750MCM AWG Copper Tubular Lugs (T) T400-12 | T400-12 | 1/2" | 0.520 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI2 | 600/750MCM AWG Copper Tubular Lugs (T) T400-14 | T400-14 | 9/16" | 0.571 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI3 | 600/750MCM AWG Copper Tubular Lugs (T) T400-16 | T400-16 | 5/8" | 0.650 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFL1TI4 | 600/750MCM AWG Copper Tubular Lugs (T) T400-20 | T400-20 | 3/4" | 0.827 | 1.890 | 4.122 | 1.291 | 1.055 | 1.457 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ0 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-10 | T500-10 | 3/8" | 0.413 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ1 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-12 | T500-12 | 1/2" | 0.520 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ2 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-14 | T500-14 | 9/16" | 0.571 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ3 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-16 | T500-16 | 5/8" | 0.650 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFL1TJ4 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-20 | T500-20 | 3/4" | 0.827 | 2.165 | 4.547 | 1.512 | 1.173 | 1.831 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK0 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-10 | T630-10 | 3/8" | 0.413 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK1 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-12 | T630-12 | 1/2" | 0.520 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK2 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-14 | T630-14 | 9/16" | 0.571 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK3 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-16 | T630-16 | 5/8" | 0.650 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFL1TK4 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-20 | T630-20 | 3/4" | 0.827 | 2.520 | 5.240 | 1.760 | 1.358 | 1.969 | IZUMI EP-1000A | 5 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 1.5mm² | KFL1T10 | 16 AWG Copper Tubular Lugs (T) T1.5-4 | T1.5-4 | 4 | 4.3 | 8.7 | 19.0 | 4.0 | 2.4 | 7.00 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFL1T11 | 16 AWG Copper Tubular Lugs (T) T1.5-5 | T1.5-5 | 5 | 5.3 | 8.7 | 19.0 | 4.0 | 2.4 | 7.00 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFL1T12 | 16 AWG Copper Tubular Lugs (T) T1.5-6 | T1.5-6 | 6 | 6.4 | 10.0 | 20.0 | 4.0 | 2.4 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T20 | 14 AWG Copper Tubular Lugs (T) T2.5-4 | T2.5-4 | 4 | 4.3 | 8.7 | 19.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T21 | 14 AWG Copper Tubular Lugs (T) T2.5-5 | T2.5-5 | 5 | 5.3 | 8.7 | 19.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T22 | 14 AWG Copper Tubular Lugs (T) T2.5-6 | T2.5-6 | 6 | 6.4 | 10.3 | 21.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFL1T23 | 14 AWG Copper Tubular Lugs (T) T2.5-8 | T2.5-8 | 8 | 8.3 | 12.0 | 23.0 | 4.3 | 2.7 | 7.00 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T30 | 12 AWG Copper Tubular Lugs (T) T4-4 | T4-4 | 4 | 4.3 | 8.7 | 21.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T31 | 12 AWG Copper Tubular Lugs (T) T4-5 | T4-5 | 5 | 5.3 | 8.7 | 21.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T32 | 12 AWG Copper Tubular Lugs (T) T4-6 | T4-6 | 6 | 6.4 | 10.3 | 23.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 4.0mm² | KFL1T33 | 12 AWG Copper Tubular Lugs (T) T4-8 | T4-8 | 8 | 8.3 | 12.5 | 28.5 | 4.8 | 3.1 | 9.50 | IZUMI 5N18 | 1000 |
| 6.0mm² | KFL1T40 | 10 AWG Copper Tubular Lugs (T) T6-4 | T6-4 | 4 | 4.3 | 10.3 | 26.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T41 | 10 AWG Copper Tubular Lugs (T) T6-5 | T6-5 | 5 | 5.3 | 10.3 | 26.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T42 | 10 AWG Copper Tubular Lugs (T) T6-6 | T6-6 | 6 | 6.4 | 10.3 | 26.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T43 | 10 AWG Copper Tubular Lugs (T) T6-8 | T6-7 | 7 | 8.3 | 13.9 | 29.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 6.0mm² | KFL1T44 | 10 AWG Copper Tubular Lugs (T) T6-10 | T6-10 | 10 | 10.5 | 13.9 | 29.0 | 5.5 | 3.8 | 10.00 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T50 | 8 AWG Copper Tubular Lugs (T) T10-4 | T10-4 | 4 | 4.3 | 11.9 | 27.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T51 | 8 AWG Copper Tubular Lugs (T) T10-5 | T10-5 | 5 | 5.3 | 11.9 | 27.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T52 | 8 AWG Copper Tubular Lugs (T) T10-6 | T10-6 | 6 | 6.4 | 11.9 | 27.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T53 | 8 AWG Copper Tubular Lugs (T) T10-8 | T10-8 | 8 | 8.3 | 13.5 | 30.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T54 | 8 AWG Copper Tubular Lugs (T) T10-10 | T10-10 | 10 | 10.5 | 15.0 | 30.5 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 10.0mm² | KFL1T55 | 8 AWG Copper Tubular Lugs (T) T10-12 | T10-12 | 12 | 13.2 | 17.0 | 34.0 | 6.9 | 4.7 | 11.50 | IZUMI 5N18 | 500 |
| 16.0mm² | KFL1T60 | 6 AWG Copper Tubular Lugs (T) T16-5 | T16-5 | 5 | 5.3 | 12.0 | 27.5 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T61 | 6 AWG Copper Tubular Lugs (T) T16-6 | T16-6 | 6 | 6.4 | 12.0 | 27.5 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T62 | 6 AWG Copper Tubular Lugs (T) T16-8 | T16-8 | 8 | 8.3 | 13.5 | 21.0 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T63 | 6 AWG Copper Tubular Lugs (T) T16-10 | T16-10 | 10 | 10.5 | 16.0 | 32.0 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 16.0mm² | KFL1T64 | 6 AWG Copper Tubular Lugs (T) T16-12 | T16-12 | 12 | 13.2 | 17.0 | 37.5 | 7.8 | 5.6 | 12.00 | OPT TP-150D | 500 |
| 25.0mm | KFL1T70 | 4 AWG Copper Tubular Lugs (T) T25-6 | T25-6 | 6 | 6.4 | 14.0 | 34.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 25.0mm | KFL1T71 | 4 AWG Copper Tubular Lugs (T) T25-8 | T25-8 | 8 | 8.3 | 14.0 | 34.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 25.0mm | KFL1T72 | 4 AWG Copper Tubular Lugs (T) T25-10 | T25-10 | 10 | 10.5 | 16.0 | 37.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 25.0mm | KFL1T73 | 4 AWG Copper Tubular Lugs (T) T25-12 | T25-12 | 12 | 13.2 | 18.0 | 40.0 | 9.5 | 7.1 | 13.50 | OPT TP-150D | 250 |
| 35mm² | KFL1T80 | 2 AWG Copper Tubular Lugs (T) T35-6 | T35-6 | 6 | 6.4 | 16.5 | 39.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T81 | 2 AWG Copper Tubular Lugs (T) T35-8 | T35-8 | 8 | 8.3 | 16.5 | 39.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T82 | 2 AWG Copper Tubular Lugs (T) T35-10 | T35-10 | 10 | 10.5 | 16.5 | 43.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T83 | 2 AWG Copper Tubular Lugs (T) T35-12 | T35-12 | 12 | 13.2 | 18.0 | 43.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T84 | 2 AWG Copper Tubular Lugs (T) T35-14 | T35-14 | 14 | 14.5 | 20.0 | 48.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 35mm² | KFL1T85 | 2 AWG Copper Tubular Lugs (T) T35-16 | T35-16 | 16 | 16.5 | 23.0 | 48.0 | 11.0 | 8.2 | 16.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T90 | 1 AWG Copper Tubular Lugs (T) T40-6 | T40-6 | 6 | 6.4 | 17.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T91 | 1 AWG Copper Tubular Lugs (T) T40-8 | T40-8 | 8 | 8.3 | 17.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T92 | 1 AWG Copper Tubular Lugs (T) T40-10 | T40-10 | 10 | 10.5 | 17.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 40mm² | KFL1T93 | 1 AWG Copper Tubular Lugs (T) T40-12 | T40-12 | 12 | 13.2 | 18.0 | 44.0 | 11.2 | 9.0 | 17.0 | OPT TP-150D | 200 |
| 50mm² | KFL1TA0 | 1/0 AWG Copper Tubular Lugs (T) T50-6 | T50-6 | 6 | 6.4 | 18.0 | 45.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA1 | 1/0 AWG Copper Tubular Lugs (T) T50-8 | T50-8 | 8 | 8.3 | 18.0 | 45.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA2 | 1/0 AWG Copper Tubular Lugs (T) T50-10 | T50-10 | 10 | 10.5 | 18.0 | 49.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA3 | 1/0 AWG Copper Tubular Lugs (T) T50-12 | T50-12 | 12 | 13.2 | 18.0 | 49.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA4 | 1/0 AWG Copper Tubular Lugs (T) T50-14 | T50-14 | 14 | 14.5 | 22.0 | 54.0 | 12.5 | 9.5 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA5 | 1/0 AWG Copper Tubular Lugs (T) T50-16 | T50-16 | 16 | 16.5 | 25.0 | 62.0 | 14.0 | 9.5 | 23.0 | OPT TP-150D | 100 |
| 50mm² | KFL1TA6 | 1/0 AWG Copper Tubular Lugs (T) T50-20 | T50-20 | 20 | 21.0 | 30.0 | 68.0 | 14.0 | 9.5 | 23.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB0 | 2/0 AWG Copper Tubular Lugs (T) T70-8 | T70-8 | 8 | 8.3 | 22.0 | 47.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB1 | 2/0 AWG Copper Tubular Lugs (T) T70-10 | T70-10 | 10 | 10.5 | 22.0 | 51.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB2 | 2/0 AWG Copper Tubular Lugs (T) T70-12 | T70-12 | 12 | 13.2 | 22.0 | 51.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB3 | 2/0 AWG Copper Tubular Lugs (T) T70-14 | T70-14 | 14 | 14.5 | 22.0 | 62.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB4 | 2/0 AWG Copper Tubular Lugs (T) T70-16 | T70-16 | 16 | 16.5 | 22.0 | 62.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFL1TB5 | 2/0 AWG Copper Tubular Lugs (T) T70-20 | T70-20 | 20 | 21.0 | 30.0 | 62.6 | 15.0 | 11.5 | 20.0 | OPT TP-150D | 100 |
| 95mm² | KFL1TC0 | 3/0 AWG Copper Tubular Lugs (T) T95-8 | T95-8 | 8 | 8.3 | 25.0 | 55.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC1 | 3/0 AWG Copper Tubular Lugs (T) T95-10 | T95-10 | 10 | 10.5 | 25.0 | 55.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC2 | 3/0 AWG Copper Tubular Lugs (T) T95-12 | T95-12 | 12 | 13.2 | 25.0 | 55.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC3 | 3/0 AWG Copper Tubular Lugs (T) T95-14 | T95-14 | 14 | 14.5 | 25.0 | 66.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC4 | 3/0 AWG Copper Tubular Lugs (T) T95-16 | T95-16 | 16 | 16.5 | 25.0 | 66.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 95mm² | KFL1TC5 | 3/0 AWG Copper Tubular Lugs (T) T95-20 | T95-20 | 20 | 21.0 | 28.0 | 66.8 | 17.0 | 13.5 | 22.0 | OPT TP-150D | 50 |
| 120mm² | KFL1TD0 | 4/0 AWG Copper Tubular Lugs (T) T120-10 | T120-10 | 10 | 10.5 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD1 | 4/0 AWG Copper Tubular Lugs (T) T120-12 | T120-12 | 12 | 13.2 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD2 | 4/0 AWG Copper Tubular Lugs (T) T120-14 | T120-14 | 14 | 14.5 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD3 | 4/0 AWG Copper Tubular Lugs (T) T120-16 | T120-16 | 16 | 16.5 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 120mm² | KFL1TD4 | 4/0 AWG Copper Tubular Lugs (T) T120-20 | T120-20 | 20 | 21.0 | 29.0 | 71.5 | 20.0 | 15.6 | 27.0 | IZUMI EP-520C | 30 |
| 150mm² | KFL1TE0 | 250/300MCM AWG Copper Tubular Lugs (T) T150-10 | T150-10 | 10 | 10.5 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE1 | 250/300MCM AWG Copper Tubular Lugs (T) T150-12 | T150-12 | 12 | 13.2 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE2 | 250/300MCM AWG Copper Tubular Lugs (T) T150-14 | T150-14 | 14 | 14.5 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE3 | 250/300MCM AWG Copper Tubular Lugs (T) T150-16 | T150-16 | 16 | 16.5 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 150mm² | KFL1TE4 | 250/300MCM AWG Copper Tubular Lugs (T) T150-20 | T150-20 | 20 | 21.0 | 30.6 | 78.0 | 21.0 | 16.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF0 | 300/350MCM AWG Copper Tubular Lugs (T) T185-10 | T185-10 | 10 | 10.5 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF1 | 300/350MCM AWG Copper Tubular Lugs (T) T185-12 | T185-12 | 12 | 13.2 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF2 | 300/350MCM AWG Copper Tubular Lugs (T) T185-14 | T185-14 | 14 | 14.5 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF3 | 300/350MCM AWG Copper Tubular Lugs (T) T185-16 | T185-16 | 16 | 16.5 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFL1TF4 | 300/350MCM AWG Copper Tubular Lugs (T) T185-20 | T185-20 | 20 | 21.0 | 34.0 | 84.0 | 23.6 | 18.4 | 34.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG0 | 400MCM AWG Copper Tubular Lugs (T) T240-10 | T240-10 | 10 | 10.5 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG1 | 400MCM AWG Copper Tubular Lugs (T) T240-12 | T240-12 | 12 | 13.2 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG2 | 400MCM AWG Copper Tubular Lugs (T) T240-14 | T240-14 | 14 | 14.5 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG3 | 400MCM AWG Copper Tubular Lugs (T) T240-16 | T240-16 | 16 | 16.5 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 240mm² | KFL1TG4 | 400MCM AWG Copper Tubular Lugs (T) T240-20 | T240-20 | 20 | 21.0 | 38.5 | 90.0 | 26.4 | 21.2 | 37.0 | IZUMI EP-520C | 10 |
| 300mm² | KFL1TH0 | 500MCM AWG Copper Tubular Lugs (T) T300-10 | T300-10 | 10 | 10.5 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH1 | 500MCM AWG Copper Tubular Lugs (T) T300-12 | T300-12 | 12 | 13.2 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH2 | 500MCM AWG Copper Tubular Lugs (T) T300-14 | T300-14 | 14 | 14.5 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH3 | 500MCM AWG Copper Tubular Lugs (T) T300-16 | T300-16 | 16 | 16.5 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFL1TH4 | 500MCM AWG Copper Tubular Lugs (T) T300-20 | T300-20 | 20 | 21.0 | 42.0 | 96.0 | 28.6 | 23.4 | 40.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI0 | 600/750MCM AWG Copper Tubular Lugs (T) T400-10 | T400-10 | 10 | 10.5 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI1 | 600/750MCM AWG Copper Tubular Lugs (T) T400-12 | T400-12 | 12 | 13.2 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI2 | 600/750MCM AWG Copper Tubular Lugs (T) T400-14 | T400-14 | 14 | 14.5 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI3 | 600/750MCM AWG Copper Tubular Lugs (T) T400-16 | T400-16 | 16 | 16.5 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFL1TI4 | 600/750MCM AWG Copper Tubular Lugs (T) T400-20 | T400-20 | 20 | 21.0 | 48.0 | 104.7 | 32.8 | 26.8 | 37.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ0 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-10 | T500-10 | 10 | 10.5 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ1 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-12 | T500-12 | 12 | 13.2 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ2 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-14 | T500-14 | 14 | 14.5 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ3 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-16 | T500-16 | 16 | 16.5 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 500mm² | KFL1TJ4 | 800/1000MCM AWG Copper Tubular Lugs (T) T500-20 | T500-20 | 20 | 21.0 | 55.0 | 115.5 | 38.4 | 29.8 | 46.5 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK0 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-10 | T630-10 | 10 | 10.5 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK1 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-12 | T630-12 | 12 | 13.2 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK2 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-14 | T630-14 | 14 | 14.5 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK3 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-16 | T630-16 | 16 | 16.5 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFL1TK4 | 1000/1250MCM AWG Copper Tubular Lugs (T) T630-20 | T630-20 | 20 | 21.0 | 64.0 | 133.1 | 44.7 | 34.5 | 50.0 | IZUMI EP-1000A | 5 |
You can tick the products you need and communicate with us in the message board.
Rachel.Yue
Curry.Wang
Gavin.Peng
Lee Han
Cathy.Sun
Jackie.Li
Kageyama.Wang
Jasmine.Zhang
Allen Mo
Joan.Mo
Patrick.Delz
Xing.Chen
