Brand |
KF |
|
Finish/Coating |
Tinned |
|
Base Materials |
Copper |
|
Insulation Material |
N/A |
|
Brazed |
Seam |
|
Wire/Cable Type |
Regular Wire |
|
Color Code |
Standard |
|
MOQ |
1000Pcs/item |
|
Payment Terms |
Based on orders |
|
Delivery |
FOB/CIF/DDP |
| Spec (American AWG) | 16 | 14 | 12 | 10 | 8 | 6 | 4 | 2 | 1/0 | 2/0 | 3/0 | 4/0 | 250/300MCM | 300/350MCM | 400MCM | 500MCM | 600/750MCM | 800/1000MCM | 1000/1250MCM | 1500/1750MCM | 2000MCM |
| Spec (JIS AWG) | 1.5 | 2.5 | 4 | 6 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 | 185 | 240 | 300 | 400 | 500 | 630 | 800 | 1000 |
| Spec (DIN AWG) | |||||||||||||||||||||
| Spec (GB mm2) | |||||||||||||||||||||
| Max Current | 18 | 30 | 35 | 50 | 70 | 95 | 125 | 170 | 230 | 265 | 310 | 360 | 445 | 505 | 545 | 620 | 785 | 935 | 1065 | 1280 | 1385 |
You can tick the products you need and communicate with us in the message board.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 16 | KFLDA10 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-4 | SC1.5-4 | #8 | 0.169 | 0.295 | 0.709 | 0.122 | 0.075 | 0.256 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFLDA11 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-5 | SC1.5-5 | #10 | 0.205 | 0.315 | 0.709 | 0.122 | 0.075 | 0.256 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFLDA12 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-6 | SC1.5-6 | 1/4" | 0.256 | 0.362 | 0.709 | 0.134 | 0.075 | 0.256 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFLDA20 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-4 | SC2.5-4 | #8 | 0.169 | 0.315 | 0.748 | 0.157 | 0.110 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFLDA21 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-5 | SC2.5-5 | #10 | 0.205 | 0.32 | 0.787 | 0.157 | 0.110 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFLDA22 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-6 | SC2.5-6 | 1/4" | 0.256 | 0.36 | 0.787 | 0.157 | 0.102 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA30 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-4 | SC4-4 | #8 | 0.169 | 0.315 | 0.768 | 0.177 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA31 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-5 | SC4-5 | #10 | 0.205 | 0.315 | 0.807 | 0.177 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA32 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-6 | SC4-6 | 1/4" | 0.256 | 0.362 | 0.866 | 0.177 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA33 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-8 | SC4-8 | 5/16" | 0.335 | 0.472 | 0.925 | 0.189 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 10 | KFLDA40 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-5 | SC6-5 | #10 | 0.205 | 0.362 | 0.866 | 0.201 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLDA41 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-6 | SC6-6 | 1/4" | 0.256 | 0.386 | 0.91 | 0.201 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLDA42 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-8 | SC6-8 | 5/16" | 0.335 | 0.472 | 0.95 | 0.209 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLDA43 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-10 | SC6-10 | 3/8" | 0.406 | 0.504 | 0.95 | 0.209 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA50 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-5 | SC10-5 | #10 | 0.205 | 0.406 | 0.945 | 0.240 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA51 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-6 | SC10-6 | 1/4" | 0.256 | 0.406 | 0.945 | 0.240 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA52 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-8 | SC10-8 | 5/16" | 0.335 | 0.472 | 0.984 | 0.240 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA53 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-10 | SC10-10 | 3/8" | 0.406 | 0.520 | 1.043 | 0.248 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFLDA60 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-6 | SC16-6 | 1/4" | 0.256 | 0.433 | 1.083 | 0.287 | 0.224 | 0.433 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLDA61 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-8 | SC16-8 | 5/16" | 0.335 | 0.492 | 1.16 | 0.29 | 0.224 | 0.433 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLDA62 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-10 | SC16-10 | 3/8" | 0.413 | 0.551 | 1.18 | 0.30 | 0.224 | 0.433 | OPT TP-150D | 500 |
| A.W.G. 4 | KFLDA70 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-6 | SC25-6 | 1/4" | 0.256 | 0.516 | 1.280 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLDA71 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-8 | SC25-8 | 5/16" | 0.335 | 0.516 | 1.299 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLDA72 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-10 | SC25-10 | 3/8" | 0.413 | 0.571 | 1.339 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLDA73 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-12 | SC25-12 | 1/2" | 0.512 | 0.650 | 1.457 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 2 | KFLDA80 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-6 | SC35-6 | 1/4" | 0.256 | 0.622 | 1.417 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLDA81 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-8 | SC35-8 | 5/16" | 0.335 | 0.622 | 1.457 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLDA82 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-10 | SC35-10 | 3/8" | 0.413 | 0.622 | 1.496 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLDA83 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-12 | SC35-12 | 1/2" | 0.512 | 0.685 | 1.496 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFLDA90 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-6 | SC50-6 | 1/4" | 0.256 | 0.713 | 1.614 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLDA91 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-8 | SC50-8 | 5/16" | 0.335 | 0.713 | 1.673 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLDA92 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-10 | SC50-10 | 3/8" | 0.413 | 0.717 | 1.732 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLDA93 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-12 | SC50-12 | 1/2" | 0.512 | 0.717 | 1.732 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA0 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-6 | SC70-6 | 1/4" | 0.256 | 0.827 | 1.909 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA1 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-8 | SC70-8 | 5/16" | 0.335 | 0.827 | 1.91 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA2 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-10 | SC70-10 | 3/8" | 0.413 | 0.827 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA3 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-12 | SC70-12 | 1/2" | 0.512 | 0.827 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA4 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-14 | SC70-14 | 9/16" | 0.591 | 0.827 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA5 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-16 | SC70-16 | 5/8" | 0.669 | 0.906 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFLDAB0 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-8 | SC95-8 | 5/16" | 0.335 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB1 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-10 | SC95-10 | 3/8" | 0.413 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB2 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-12 | SC95-12 | 1/2" | 0.512 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB3 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-14 | SC95-14 | 9/16" | 0.591 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB4 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-16 | SC95-16 | 5/8" | 0.669 | 1.024 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFLDAC0 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-8 | SC120-8 | 5/16" | 0.335 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC1 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-10 | SC120-10 | 3/8" | 0.413 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC2 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-12 | SC120-12 | 1/2" | 0.512 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC3 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-14 | SC120-14 | 9/16" | 0.591 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC4 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-16 | SC120-16 | 5/8" | 0.669 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC5 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-20 | SC120-20 | 3/4" | 0.827 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFLDAD0 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-8 | SC150-8 | 5/16" | 0.335 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD1 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-10 | SC150-10 | 3/8" | 0.413 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD2 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-12 | SC150-12 | 1/2" | 0.512 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD3 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-14 | SC150-14 | 9/16" | 0.591 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD4 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-16 | SC150-16 | 5/8" | 0.669 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD5 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-20 | SC150-20 | 3/4" | 0.827 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE0 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-10 | SC185-10 | 3/8" | 0.413 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE1 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-12 | SC185-12 | 1/2" | 0.512 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE2 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-14 | SC185-14 | 9/16" | 0.591 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE3 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-16 | SC185-16 | 5/8" | 0.669 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE4 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-20 | SC185-20 | 3/4" | 0.827 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF0 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-10 | SC240-10 | 3/8" | 0.413 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF1 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-12 | SC240-12 | 1/2" | 0.512 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF2 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-14 | SC240-14 | 9/16" | 0.591 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF3 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-16 | SC240-16 | 5/8" | 0.669 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF4 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-18 | SC240-18 | 11/16" | 0.748 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF5 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-20 | SC240-20 | 3/4" | 0.827 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFLDAG0 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-10 | SC300-10 | 3/8" | 0.413 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG1 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-12 | SC300-12 | 1/2" | 0.512 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG2 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-14 | SC300-14 | 9/16" | 0.591 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG3 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-16 | SC300-16 | 5/8" | 0.669 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG4 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-20 | SC300-20 | 3/4" | 0.827 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH0 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-10 | SC400-10 | 3/8" | 0.413 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH1 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-12 | SC400-12 | 1/2" | 0.512 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH2 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-14 | SC400-14 | 9/16" | 0.591 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH3 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-16 | SC400-16 | 5/8" | 0.669 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH4 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-20 | SC400-20 | 3/4" | 0.827 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI0 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-10 | SC500-10 | 3/8" | 0.413 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI1 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-12 | SC500-12 | 1/2" | 0.512 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI2 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-14 | SC500-14 | 9/16" | 0.591 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI4 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-16 | SC500-16 | 5/8" | 0.669 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI5 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-20 | SC500-20 | 3/4" | 0.827 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ0 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-10 | SC630-10 | 3/8" | 0.413 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ1 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-12 | SC630-12 | 1/2" | 0.512 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ2 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-14 | SC630-14 | 9/16" | 0.591 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ3 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-16 | SC630-16 | 5/8" | 0.669 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ4 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-20 | SC630-20 | 3/4" | 0.827 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1500/1750MCM | KFLDAK5 | 1500/1750MCM AWG Copper Tubular Lugs (Type DTGA) SC800-20 | SC800-20 | 3/4" | 0.827 | 2.835 | 6.693 | 1.969 | 1.535 | 2.362 | IZUMI EP-1000A | 1 |
| A.W.G. 2000MCM | KFLDAL0 | 2000MCM AWG Copper Tubular Lugs (Type DTGA) SC1000-22 | SC1000-22 | 7/8" | 0.906 | 3.189 | 7.874 | 2.205 | 1.732 | 3.425 | IZUMI EP-1000A | 1 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 1.5mm² | KFLDA10 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-4 | SC1.5-4 | 4 | 4.3 | 7.5 | 18.0 | 3.1 | 1.9 | 6.5 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFLDA11 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-5 | SC1.5-5 | 5 | 5.2 | 8.0 | 18.0 | 3.1 | 1.9 | 6.5 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFLDA12 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-6 | SC1.5-6 | 6 | 6.5 | 9.2 | 18.0 | 3.4 | 1.9 | 6.5 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFLDA20 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-4 | SC2.5-4 | 4 | 4.3 | 8.0 | 19.0 | 4.0 | 2.8 | 7.0 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFLDA21 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-5 | SC2.5-5 | 5 | 5.2 | 8.0 | 20.0 | 4.0 | 2.8 | 7.0 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFLDA22 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-6 | SC2.5-6 | 6 | 6.5 | 9.2 | 20.0 | 4.0 | 2.6 | 7.0 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA30 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-4 | SC4-4 | 4 | 4.3 | 8.0 | 19.5 | 4.5 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA31 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-5 | SC4-5 | 5 | 5.2 | 8.0 | 20.5 | 4.5 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA32 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-6 | SC4-6 | 6 | 6.5 | 9.2 | 22.0 | 4.5 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA33 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-8 | SC4-8 | 8 | 8.5 | 12.0 | 23.5 | 4.8 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 16mm² | KFLDA40 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-5 | SC6-5 | 5 | 5.2 | 9.2 | 22.0 | 5.1 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA41 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-6 | SC6-6 | 6 | 6.5 | 9.8 | 23.0 | 5.1 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA42 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-8 | SC6-8 | 8 | 8.5 | 12.0 | 24.0 | 5.3 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA43 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-10 | SC6-10 | 10 | 10.3 | 12.8 | 24.0 | 5.3 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA50 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-5 | SC10-5 | 5 | 5.2 | 10.3 | 24.0 | 6.1 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA51 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-6 | SC10-6 | 6 | 6.5 | 10.3 | 24.0 | 6.1 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA52 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-8 | SC10-8 | 8 | 8.5 | 12.0 | 25.0 | 6.1 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA53 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-10 | SC10-10 | 10 | 10.3 | 13.2 | 26.5 | 6.3 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA60 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-6 | SC16-6 | 6 | 6.5 | 11.0 | 27.5 | 7.3 | 5.7 | 11.0 | OPT TP-150D | 500 |
| 16mm² | KFLDA61 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-8 | SC16-8 | 8 | 8.5 | 12.5 | 29.5 | 7.3 | 5.7 | 11.0 | OPT TP-150D | 500 |
| 16mm² | KFLDA62 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-10 | SC16-10 | 10 | 10.5 | 14.0 | 30.0 | 7.5 | 5.7 | 11.0 | OPT TP-150D | 500 |
| 25mm² | KFLDA70 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-6 | SC25-6 | 6 | 6.5 | 13.1 | 32.5 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 25mm² | KFLDA71 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-8 | SC25-8 | 8 | 8.5 | 13.1 | 33.0 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 25mm² | KFLDA72 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-10 | SC25-10 | 10 | 10.5 | 14.5 | 34.0 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 25mm² | KFLDA73 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-12 | SC25-12 | 12 | 13.0 | 16.5 | 37.0 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 35mm² | KFLDA80 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-6 | SC35-6 | 6 | 6.5 | 15.8 | 36.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 35mm² | KFLDA81 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-8 | SC35-8 | 8 | 8.5 | 15.8 | 37.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 35mm² | KFLDA82 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-10 | SC35-10 | 10 | 10.5 | 15.8 | 38.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 35mm² | KFLDA83 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-12 | SC35-12 | 12 | 13.0 | 17.4 | 38.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 50mm² | KFLDA90 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-6 | SC50-6 | 6 | 6.5 | 18.1 | 41.0 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLDA91 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-8 | SC50-8 | 8 | 8.5 | 18.1 | 42.5 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLDA92 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-10 | SC50-10 | 10 | 10.5 | 18.2 | 44.0 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLDA93 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-12 | SC50-12 | 12 | 13.0 | 18.2 | 44.0 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 70mm² | KFLDAA0 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-6 | SC70-6 | 6 | 6.5 | 21.0 | 48.5 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA1 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-8 | SC70-8 | 8 | 8.5 | 21.0 | 48.5 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA2 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-10 | SC70-10 | 10 | 10.5 | 21.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA3 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-12 | SC70-12 | 12 | 13.0 | 21.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA4 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-14 | SC70-14 | 14 | 15.0 | 21.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA5 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-16 | SC70-16 | 16 | 17.0 | 23.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 95mm² | KFLDAB0 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-8 | SC95-8 | 8 | 8.5 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB1 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-10 | SC95-10 | 10 | 10.5 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB2 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-12 | SC95-12 | 12 | 13.0 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB3 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-14 | SC95-14 | 14 | 15.0 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB4 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-16 | SC95-16 | 16 | 17.0 | 26.0 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 120mm² | KFLDAC1 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-8 | SC120-8 | 8 | 8.5 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC2 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-10 | SC120-10 | 10 | 10.5 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC3 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-12 | SC120-12 | 12 | 13.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC4 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-14 | SC120-14 | 14 | 15.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC5 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-16 | SC120-16 | 16 | 17.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC6 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-20 | SC120-20 | 20 | 21.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 150mm² | KFLDAD0 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-8 | SC150-8 | 8 | 8.5 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD1 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-10 | SC150-10 | 10 | 10.5 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD2 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-12 | SC150-12 | 12 | 13.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD3 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-14 | SC150-14 | 14 | 15.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD4 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-16 | SC150-16 | 16 | 17.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD5 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-20 | SC150-20 | 20 | 21.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE0 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-10 | SC185-10 | 10 | 10.5 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE1 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-12 | SC185-12 | 12 | 13.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE2 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-14 | SC185-14 | 14 | 15.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE3 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-16 | SC185-16 | 16 | 17.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE4 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-20 | SC185-20 | 20 | 21.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF0 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-10 | SC240-10 | 10 | 10.5 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF1 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-12 | SC240-12 | 12 | 13.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF2 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-14 | SC240-14 | 14 | 15.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF3 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-16 | SC240-16 | 16 | 17.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF4 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-18 | SC240-18 | 18 | 19.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF5 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-20 | SC240-20 | 20 | 21.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 300mm² | KFLDAG0 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-10 | SC300-10 | 10 | 10.5 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG1 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-12 | SC300-12 | 12 | 13.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG2 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-14 | SC300-14 | 14 | 15.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG3 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-16 | SC300-16 | 16 | 17.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG4 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-20 | SC300-20 | 20 | 21.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH0 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-10 | SC400-10 | 10 | 10.5 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH1 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-12 | SC400-12 | 12 | 13.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH2 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-14 | SC400-14 | 14 | 15.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH3 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-16 | SC400-16 | 16 | 17.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH4 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-20 | SC400-20 | 20 | 21.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI0 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-10 | SC500-10 | 10 | 10.5 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI1 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-12 | SC500-12 | 12 | 13.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI2 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-14 | SC500-14 | 14 | 15.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI3 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-16 | SC500-16 | 16 | 17.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI4 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-20 | SC500-20 | 20 | 21.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ0 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-10 | SC630-10 | 10 | 10.5 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ1 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-12 | SC630-12 | 12 | 13.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ2 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-14 | SC630-14 | 14 | 15.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ3 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-16 | SC630-16 | 16 | 17.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ4 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-20 | SC630-20 | 20 | 21.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 800mm² | KFLDAK0 | 1500/1750MCM AWG Copper Tubular Lugs (Type DTGA) SC800-20 | SC800-20 | 20 | 21.0 | 72.0 | 170.0 | 50.0 | 39.0 | 60.0 | IZUMI EP-1000A | 1 |
| 1000mm² | KFLDAL0 | 2000MCM AWG Copper Tubular Lugs (Type DTGA) SC1000-22 | SC1000-22 | 22 | 23.0 | 81.0 | 200.0 | 56.0 | 44.0 | 87.0 | IZUMI EP-1000A | 1 |
Want to get a sample? Please fill in the form, leave your contact information and parameter information.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 16 | KFLDA10 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-4 | SC1.5-4 | #8 | 0.169 | 0.295 | 0.709 | 0.122 | 0.075 | 0.256 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFLDA11 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-5 | SC1.5-5 | #10 | 0.205 | 0.315 | 0.709 | 0.122 | 0.075 | 0.256 | IZUMI 5N18 | 1000 |
| A.W.G. 16 | KFLDA12 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-6 | SC1.5-6 | 1/4" | 0.256 | 0.362 | 0.709 | 0.134 | 0.075 | 0.256 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFLDA20 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-4 | SC2.5-4 | #8 | 0.169 | 0.315 | 0.748 | 0.157 | 0.110 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFLDA21 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-5 | SC2.5-5 | #10 | 0.205 | 0.32 | 0.787 | 0.157 | 0.110 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 14 | KFLDA22 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-6 | SC2.5-6 | 1/4" | 0.256 | 0.36 | 0.787 | 0.157 | 0.102 | 0.276 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA30 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-4 | SC4-4 | #8 | 0.169 | 0.315 | 0.768 | 0.177 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA31 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-5 | SC4-5 | #10 | 0.205 | 0.315 | 0.807 | 0.177 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA32 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-6 | SC4-6 | 1/4" | 0.256 | 0.362 | 0.866 | 0.177 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 12 | KFLDA33 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-8 | SC4-8 | 5/16" | 0.335 | 0.472 | 0.925 | 0.189 | 0.126 | 0.295 | IZUMI 5N18 | 1000 |
| A.W.G. 10 | KFLDA40 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-5 | SC6-5 | #10 | 0.205 | 0.362 | 0.866 | 0.201 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLDA41 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-6 | SC6-6 | 1/4" | 0.256 | 0.386 | 0.91 | 0.201 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLDA42 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-8 | SC6-8 | 5/16" | 0.335 | 0.472 | 0.95 | 0.209 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLDA43 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-10 | SC6-10 | 3/8" | 0.406 | 0.504 | 0.95 | 0.209 | 0.146 | 0.315 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA50 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-5 | SC10-5 | #10 | 0.205 | 0.406 | 0.945 | 0.240 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA51 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-6 | SC10-6 | 1/4" | 0.256 | 0.406 | 0.945 | 0.240 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA52 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-8 | SC10-8 | 5/16" | 0.335 | 0.472 | 0.984 | 0.240 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLDA53 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-10 | SC10-10 | 3/8" | 0.406 | 0.520 | 1.043 | 0.248 | 0.177 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFLDA60 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-6 | SC16-6 | 1/4" | 0.256 | 0.433 | 1.083 | 0.287 | 0.224 | 0.433 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLDA61 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-8 | SC16-8 | 5/16" | 0.335 | 0.492 | 1.16 | 0.29 | 0.224 | 0.433 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLDA62 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-10 | SC16-10 | 3/8" | 0.413 | 0.551 | 1.18 | 0.30 | 0.224 | 0.433 | OPT TP-150D | 500 |
| A.W.G. 4 | KFLDA70 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-6 | SC25-6 | 1/4" | 0.256 | 0.516 | 1.280 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLDA71 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-8 | SC25-8 | 5/16" | 0.335 | 0.516 | 1.299 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLDA72 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-10 | SC25-10 | 3/8" | 0.413 | 0.571 | 1.339 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLDA73 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-12 | SC25-12 | 1/2" | 0.512 | 0.650 | 1.457 | 0.354 | 0.283 | 0.531 | OPT TP-150D | 250 |
| A.W.G. 2 | KFLDA80 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-6 | SC35-6 | 1/4" | 0.256 | 0.622 | 1.417 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLDA81 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-8 | SC35-8 | 5/16" | 0.335 | 0.622 | 1.457 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLDA82 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-10 | SC35-10 | 3/8" | 0.413 | 0.622 | 1.496 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLDA83 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-12 | SC35-12 | 1/2" | 0.512 | 0.685 | 1.496 | 0.425 | 0.335 | 0.571 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFLDA90 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-6 | SC50-6 | 1/4" | 0.256 | 0.713 | 1.614 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLDA91 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-8 | SC50-8 | 5/16" | 0.335 | 0.713 | 1.673 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLDA92 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-10 | SC50-10 | 3/8" | 0.413 | 0.717 | 1.732 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLDA93 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-12 | SC50-12 | 1/2" | 0.512 | 0.717 | 1.732 | 0.492 | 0.386 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA0 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-6 | SC70-6 | 1/4" | 0.256 | 0.827 | 1.909 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA1 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-8 | SC70-8 | 5/16" | 0.335 | 0.827 | 1.91 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA2 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-10 | SC70-10 | 3/8" | 0.413 | 0.827 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA3 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-12 | SC70-12 | 1/2" | 0.512 | 0.827 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA4 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-14 | SC70-14 | 9/16" | 0.591 | 0.827 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLDAA5 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-16 | SC70-16 | 5/8" | 0.669 | 0.906 | 1.97 | 0.571 | 0.453 | 0.768 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFLDAB0 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-8 | SC95-8 | 5/16" | 0.335 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB1 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-10 | SC95-10 | 3/8" | 0.413 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB2 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-12 | SC95-12 | 1/2" | 0.512 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB3 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-14 | SC95-14 | 9/16" | 0.591 | 0.976 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLDAB4 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-16 | SC95-16 | 5/8" | 0.669 | 1.024 | 2.244 | 0.669 | 0.539 | 0.925 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFLDAC0 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-8 | SC120-8 | 5/16" | 0.335 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC1 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-10 | SC120-10 | 3/8" | 0.413 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC2 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-12 | SC120-12 | 1/2" | 0.512 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC3 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-14 | SC120-14 | 9/16" | 0.591 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC4 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-16 | SC120-16 | 5/8" | 0.669 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLDAC5 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-20 | SC120-20 | 3/4" | 0.827 | 1.087 | 2.480 | 0.748 | 0.591 | 1.004 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFLDAD0 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-8 | SC150-8 | 5/16" | 0.335 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD1 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-10 | SC150-10 | 3/8" | 0.413 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD2 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-12 | SC150-12 | 1/2" | 0.512 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD3 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-14 | SC150-14 | 9/16" | 0.591 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD4 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-16 | SC150-16 | 5/8" | 0.669 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLDAD5 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-20 | SC150-20 | 3/4" | 0.827 | 1.201 | 2.776 | 0.827 | 0.657 | 1.142 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE0 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-10 | SC185-10 | 3/8" | 0.413 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE1 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-12 | SC185-12 | 1/2" | 0.512 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE2 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-14 | SC185-14 | 9/16" | 0.591 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE3 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-16 | SC185-16 | 5/8" | 0.669 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLDAE4 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-20 | SC185-20 | 3/4" | 0.827 | 1.358 | 3.031 | 0.925 | 0.768 | 1.260 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF0 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-10 | SC240-10 | 3/8" | 0.413 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF1 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-12 | SC240-12 | 1/2" | 0.512 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF2 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-14 | SC240-14 | 9/16" | 0.591 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF3 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-16 | SC240-16 | 5/8" | 0.669 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF4 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-18 | SC240-18 | 11/16" | 0.748 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLDAF5 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-20 | SC240-20 | 3/4" | 0.827 | 1.496 | 3.563 | 1.024 | 0.827 | 1.535 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFLDAG0 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-10 | SC300-10 | 3/8" | 0.413 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG1 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-12 | SC300-12 | 1/2" | 0.512 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG2 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-14 | SC300-14 | 9/16" | 0.591 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG3 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-16 | SC300-16 | 5/8" | 0.669 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLDAG4 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-20 | SC300-20 | 3/4" | 0.827 | 1.720 | 3.937 | 1.181 | 0.945 | 1.713 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH0 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-10 | SC400-10 | 3/8" | 0.413 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH1 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-12 | SC400-12 | 1/2" | 0.512 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH2 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-14 | SC400-14 | 9/16" | 0.591 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH3 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-16 | SC400-16 | 5/8" | 0.669 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLDAH4 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-20 | SC400-20 | 3/4" | 0.827 | 1.949 | 4.331 | 1.339 | 1.063 | 1.811 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI0 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-10 | SC500-10 | 3/8" | 0.413 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI1 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-12 | SC500-12 | 1/2" | 0.512 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI2 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-14 | SC500-14 | 9/16" | 0.591 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI4 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-16 | SC500-16 | 5/8" | 0.669 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLDAI5 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-20 | SC500-20 | 3/4" | 0.827 | 2.165 | 4.843 | 1.496 | 1.181 | 1.969 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ0 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-10 | SC630-10 | 3/8" | 0.413 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ1 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-12 | SC630-12 | 1/2" | 0.512 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ2 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-14 | SC630-14 | 9/16" | 0.591 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ3 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-16 | SC630-16 | 5/8" | 0.669 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLDAJ4 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-20 | SC630-20 | 3/4" | 0.827 | 2.559 | 5.315 | 1.772 | 1.378 | 2.205 | IZUMI EP-1000A | 5 |
| A.W.G. 1500/1750MCM | KFLDAK5 | 1500/1750MCM AWG Copper Tubular Lugs (Type DTGA) SC800-20 | SC800-20 | 3/4" | 0.827 | 2.835 | 6.693 | 1.969 | 1.535 | 2.362 | IZUMI EP-1000A | 1 |
| A.W.G. 2000MCM | KFLDAL0 | 2000MCM AWG Copper Tubular Lugs (Type DTGA) SC1000-22 | SC1000-22 | 7/8" | 0.906 | 3.189 | 7.874 | 2.205 | 1.732 | 3.425 | IZUMI EP-1000A | 1 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 1.5mm² | KFLDA10 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-4 | SC1.5-4 | 4 | 4.3 | 7.5 | 18.0 | 3.1 | 1.9 | 6.5 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFLDA11 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-5 | SC1.5-5 | 5 | 5.2 | 8.0 | 18.0 | 3.1 | 1.9 | 6.5 | IZUMI 5N18 | 1000 |
| 1.5mm² | KFLDA12 | 16 AWG Copper Tubular Lugs (Type DTGA) SC1.5-6 | SC1.5-6 | 6 | 6.5 | 9.2 | 18.0 | 3.4 | 1.9 | 6.5 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFLDA20 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-4 | SC2.5-4 | 4 | 4.3 | 8.0 | 19.0 | 4.0 | 2.8 | 7.0 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFLDA21 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-5 | SC2.5-5 | 5 | 5.2 | 8.0 | 20.0 | 4.0 | 2.8 | 7.0 | IZUMI 5N18 | 1000 |
| 2.5mm² | KFLDA22 | 14 AWG Copper Tubular Lugs (Type DTGA) SC2.5-6 | SC2.5-6 | 6 | 6.5 | 9.2 | 20.0 | 4.0 | 2.6 | 7.0 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA30 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-4 | SC4-4 | 4 | 4.3 | 8.0 | 19.5 | 4.5 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA31 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-5 | SC4-5 | 5 | 5.2 | 8.0 | 20.5 | 4.5 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA32 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-6 | SC4-6 | 6 | 6.5 | 9.2 | 22.0 | 4.5 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 4mm² | KFLDA33 | 12 AWG Copper Tubular Lugs (Type DTGA) SC4-8 | SC4-8 | 8 | 8.5 | 12.0 | 23.5 | 4.8 | 3.2 | 7.5 | IZUMI 5N18 | 1000 |
| 16mm² | KFLDA40 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-5 | SC6-5 | 5 | 5.2 | 9.2 | 22.0 | 5.1 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA41 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-6 | SC6-6 | 6 | 6.5 | 9.8 | 23.0 | 5.1 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA42 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-8 | SC6-8 | 8 | 8.5 | 12.0 | 24.0 | 5.3 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA43 | 10 AWG Copper Tubular Lugs (Type DTGA) SC6-10 | SC6-10 | 10 | 10.3 | 12.8 | 24.0 | 5.3 | 3.7 | 8.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA50 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-5 | SC10-5 | 5 | 5.2 | 10.3 | 24.0 | 6.1 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA51 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-6 | SC10-6 | 6 | 6.5 | 10.3 | 24.0 | 6.1 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA52 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-8 | SC10-8 | 8 | 8.5 | 12.0 | 25.0 | 6.1 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLDA53 | 8 AWG Copper Tubular Lugs (Type DTGA) SC10-10 | SC10-10 | 10 | 10.3 | 13.2 | 26.5 | 6.3 | 4.5 | 9.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLDA60 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-6 | SC16-6 | 6 | 6.5 | 11.0 | 27.5 | 7.3 | 5.7 | 11.0 | OPT TP-150D | 500 |
| 16mm² | KFLDA61 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-8 | SC16-8 | 8 | 8.5 | 12.5 | 29.5 | 7.3 | 5.7 | 11.0 | OPT TP-150D | 500 |
| 16mm² | KFLDA62 | 6 AWG Copper Tubular Lugs (Type DTGA) SC16-10 | SC16-10 | 10 | 10.5 | 14.0 | 30.0 | 7.5 | 5.7 | 11.0 | OPT TP-150D | 500 |
| 25mm² | KFLDA70 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-6 | SC25-6 | 6 | 6.5 | 13.1 | 32.5 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 25mm² | KFLDA71 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-8 | SC25-8 | 8 | 8.5 | 13.1 | 33.0 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 25mm² | KFLDA72 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-10 | SC25-10 | 10 | 10.5 | 14.5 | 34.0 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 25mm² | KFLDA73 | 4 AWG Copper Tubular Lugs (Type DTGA) SC25-12 | SC25-12 | 12 | 13.0 | 16.5 | 37.0 | 9.0 | 7.2 | 13.5 | OPT TP-150D | 250 |
| 35mm² | KFLDA80 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-6 | SC35-6 | 6 | 6.5 | 15.8 | 36.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 35mm² | KFLDA81 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-8 | SC35-8 | 8 | 8.5 | 15.8 | 37.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 35mm² | KFLDA82 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-10 | SC35-10 | 10 | 10.5 | 15.8 | 38.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 35mm² | KFLDA83 | 2 AWG Copper Tubular Lugs (Type DTGA) SC35-12 | SC35-12 | 12 | 13.0 | 17.4 | 38.0 | 10.8 | 8.5 | 14.5 | OPT TP-150D | 200 |
| 50mm² | KFLDA90 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-6 | SC50-6 | 6 | 6.5 | 18.1 | 41.0 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLDA91 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-8 | SC50-8 | 8 | 8.5 | 18.1 | 42.5 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLDA92 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-10 | SC50-10 | 10 | 10.5 | 18.2 | 44.0 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLDA93 | 1/0 AWG Copper Tubular Lugs (Type DTGA) SC50-12 | SC50-12 | 12 | 13.0 | 18.2 | 44.0 | 12.5 | 9.8 | 17.0 | OPT TP-150D | 100 |
| 70mm² | KFLDAA0 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-6 | SC70-6 | 6 | 6.5 | 21.0 | 48.5 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA1 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-8 | SC70-8 | 8 | 8.5 | 21.0 | 48.5 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA2 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-10 | SC70-10 | 10 | 10.5 | 21.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA3 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-12 | SC70-12 | 12 | 13.0 | 21.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA4 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-14 | SC70-14 | 14 | 15.0 | 21.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 70mm² | KFLDAA5 | 2/0 AWG Copper Tubular Lugs (Type DTGA) SC70-16 | SC70-16 | 16 | 17.0 | 23.0 | 50.0 | 14.5 | 11.5 | 19.5 | OPT TP-150D | 100 |
| 95mm² | KFLDAB0 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-8 | SC95-8 | 8 | 8.5 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB1 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-10 | SC95-10 | 10 | 10.5 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB2 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-12 | SC95-12 | 12 | 13.0 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB3 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-14 | SC95-14 | 14 | 15.0 | 24.8 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 95mm² | KFLDAB4 | 3/0 AWG Copper Tubular Lugs (Type DTGA) SC95-16 | SC95-16 | 16 | 17.0 | 26.0 | 57.0 | 17.0 | 13.7 | 23.5 | OPT TP-150D | 50 |
| 120mm² | KFLDAC1 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-8 | SC120-8 | 8 | 8.5 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC2 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-10 | SC120-10 | 10 | 10.5 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC3 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-12 | SC120-12 | 12 | 13.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC4 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-14 | SC120-14 | 14 | 15.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC5 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-16 | SC120-16 | 16 | 17.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 120mm² | KFLDAC6 | 4/0 AWG Copper Tubular Lugs (Type DTGA) SC120-20 | SC120-20 | 20 | 21.0 | 27.6 | 63.0 | 19.0 | 15.0 | 25.5 | IZUMI EP-520C | 30 |
| 150mm² | KFLDAD0 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-8 | SC150-8 | 8 | 8.5 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD1 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-10 | SC150-10 | 10 | 10.5 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD2 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-12 | SC150-12 | 12 | 13.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD3 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-14 | SC150-14 | 14 | 15.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD4 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-16 | SC150-16 | 16 | 17.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLDAD5 | 250/300MCM AWG Copper Tubular Lugs (Type DTGA) SC150-20 | SC150-20 | 20 | 21.0 | 30.5 | 70.5 | 21.0 | 16.7 | 29.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE0 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-10 | SC185-10 | 10 | 10.5 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE1 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-12 | SC185-12 | 12 | 13.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE2 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-14 | SC185-14 | 14 | 15.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE3 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-16 | SC185-16 | 16 | 17.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLDAE4 | 300/350MCM AWG Copper Tubular Lugs (Type DTGA) SC185-20 | SC185-20 | 20 | 21.0 | 34.5 | 77.0 | 23.5 | 19.5 | 32.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF0 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-10 | SC240-10 | 10 | 10.5 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF1 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-12 | SC240-12 | 12 | 13.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF2 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-14 | SC240-14 | 14 | 15.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF3 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-16 | SC240-16 | 16 | 17.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF4 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-18 | SC240-18 | 18 | 19.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLDAF5 | 400MCM AWG Copper Tubular Lugs (Type DTGA) SC240-20 | SC240-20 | 20 | 21.0 | 38.0 | 90.5 | 26.0 | 21.0 | 39.0 | IZUMI EP-520C | 10 |
| 300mm² | KFLDAG0 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-10 | SC300-10 | 10 | 10.5 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG1 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-12 | SC300-12 | 12 | 13.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG2 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-14 | SC300-14 | 14 | 15.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG3 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-16 | SC300-16 | 16 | 17.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 300mm² | KFLDAG4 | 500MCM AWG Copper Tubular Lugs (Type DTGA) SC300-20 | SC300-20 | 20 | 21.0 | 43.7 | 100.0 | 30.0 | 24.0 | 43.5 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH0 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-10 | SC400-10 | 10 | 10.5 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH1 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-12 | SC400-12 | 12 | 13.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH2 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-14 | SC400-14 | 14 | 15.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH3 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-16 | SC400-16 | 16 | 17.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLDAH4 | 600/750MCM AWG Copper Tubular Lugs (Type DTGA) SC400-20 | SC400-20 | 20 | 21.0 | 49.5 | 110.0 | 34.0 | 27.0 | 46.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI0 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-10 | SC500-10 | 10 | 10.5 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI1 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-12 | SC500-12 | 12 | 13.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI2 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-14 | SC500-14 | 14 | 15.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI3 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-16 | SC500-16 | 16 | 17.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLDAI4 | 800/1000MCM AWG Copper Tubular Lugs (Type DTGA) SC500-20 | SC500-20 | 20 | 21.0 | 55.0 | 123.0 | 38.0 | 30.0 | 50.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ0 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-10 | SC630-10 | 10 | 10.5 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ1 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-12 | SC630-12 | 12 | 13.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ2 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-14 | SC630-14 | 14 | 15.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ3 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-16 | SC630-16 | 16 | 17.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLDAJ4 | 1000/1250MCM AWG Copper Tubular Lugs (Type DTGA) SC630-20 | SC630-20 | 20 | 21.0 | 65.0 | 135.0 | 45.0 | 35.0 | 56.0 | IZUMI EP-1000A | 5 |
| 800mm² | KFLDAK0 | 1500/1750MCM AWG Copper Tubular Lugs (Type DTGA) SC800-20 | SC800-20 | 20 | 21.0 | 72.0 | 170.0 | 50.0 | 39.0 | 60.0 | IZUMI EP-1000A | 1 |
| 1000mm² | KFLDAL0 | 2000MCM AWG Copper Tubular Lugs (Type DTGA) SC1000-22 | SC1000-22 | 22 | 23.0 | 81.0 | 200.0 | 56.0 | 44.0 | 87.0 | IZUMI EP-1000A | 1 |
You can tick the products you need and communicate with us in the message board.
Rachel.Yue
Curry.Wang
Gavin.Peng
Lee Han
Cathy.Sun
Jackie.Li
Kageyama.Wang
Jasmine.Zhang
Allen Mo
Joan.Mo
Patrick.Delz
Xing.Chen
