Brand |
KF |
|
Finish/Coating |
Tinned |
|
Base Materials |
Copper |
|
Insulation Material |
N/A |
|
Brazed |
Seam |
|
Wire/Cable Type |
Regular Wire |
|
Color Code |
Standard |
|
MOQ |
1000Pcs/item |
|
Payment Terms |
Based on orders |
|
Delivery |
FOB/CIF/DDP |
| Spec (American AWG) | 8 | 6 | 4 | 2 | 1/0 | 2/0 | 3/0 | 4/0 | 250/300MCM | 300/350MCM | 400MCM | 500MCM | 600/750MCM | 800/1000MCM | 1000/1250MCM |
| Spec (JIS AWG) | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 | 185 | 240 | 300 | 400 | 500 | 630 |
| Spec (DIN AWG) | |||||||||||||||
| Spec (GB mm2) | |||||||||||||||
| Max Current | 70 | 95 | 125 | 170 | 230 | 265 | 310 | 360 | 445 | 505 | 545 | 620 | 785 | 935 | 1065 |
You can tick the products you need and communicate with us in the message board.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 8 | KFLLF10 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-5 | LYF10-5 | #10 | 0.209 | 0.453 | 1.102 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLLF11 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-6 | LYF10-6 | 1/4" | 0.256 | 0.453 | 1.102 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLLF12 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-8 | LYF10-8 | 5/16" | 0.331 | 0.531 | 1.260 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLLF13 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-10 | LYF10-10 | 3/8" | 0.413 | 0.630 | 1.339 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFLLF20 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-6 | LYF16-6 | 1/4" | 0.256 | 0.512 | 1.299 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLLF21 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-8 | LYF16-8 | 5/16" | 0.331 | 0.512 | 1.30 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLLF22 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-10 | LYF16-10 | 3/8" | 0.413 | 0.630 | 1.50 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLLF23 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-12 | LYF16-12 | 1/2" | 0.512 | 0.866 | 1.85 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 4 | KFLLF30 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-6 | LYF25-6 | 1/4" | 0.256 | 0.630 | 1.457 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLLF31 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-8 | LYF25-8 | 5/16" | 0.331 | 0.630 | 1.496 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLLF32 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-10 | LYF25-10 | 3/8" | 0.413 | 0.669 | 1.654 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLLF33 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-12 | LYF25-12 | 1/2" | 0.512 | 0.866 | 1.850 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 2 | KFLLF40 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-6 | LYF35-6 | 1/4" | 0.256 | 0.709 | 1.732 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLLF41 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-8 | LYF35-8 | 5/16" | 0.331 | 0.709 | 1.732 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLLF42 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-10 | LYF35-10 | 3/8" | 0.413 | 0.709 | 1.732 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLLF43 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-12 | LYF35-12 | 1/2" | 0.512 | 0.866 | 2.047 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFLLF50 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-6 | LYF50-6 | 1/4" | 0.256 | 0.827 | 1.969 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLLF51 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-8 | LYF50-8 | 5/16" | 0.331 | 0.827 | 1.969 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLLF52 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-10 | LYF50-10 | 3/8" | 0.413 | 0.827 | 1.969 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLLF53 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-12 | LYF50-12 | 1/2" | 0.512 | 0.827 | 2.087 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF60 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-6 | LYF70-6 | 1/4" | 0.256 | 0.984 | 2.165 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF61 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-8 | LYF70-8 | 5/16" | 0.331 | 0.984 | 2.17 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF62 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-10 | LYF70-10 | 3/8" | 0.413 | 0.984 | 2.17 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF63 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-12 | LYF70-12 | 1/2" | 0.512 | 0.984 | 2.28 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF64 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-16 | LYF70-16 | 5/8" | 0.669 | 1.102 | 2.52 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFLLF70 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-8 | LYF95-8 | 5/16" | 0.331 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLLF71 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-10 | LYF95-10 | 3/8" | 0.413 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLLF72 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-12 | LYF95-12 | 1/2" | 0.512 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLLF73 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-16 | LYF95-16 | 5/8" | 0.669 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFLLF80 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-10 | LYF120-10 | 3/8" | 0.413 | 1.26 | 2.874 | 0.866 | 0.669 | 0.984 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLLF81 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-12 | LYF120-12 | 1/2" | 0.512 | 1.26 | 2.874 | 0.866 | 0.669 | 0.984 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLLF82 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-16 | LYF120-16 | 5/8" | 0.669 | 1.26 | 2.874 | 0.866 | 0.669 | 0.984 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFLLF90 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-10 | LYF150-10 | 3/8" | 0.413 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLLF91 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-12 | LYF150-12 | 1/2" | 0.512 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLLF92 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-16 | LYF150-16 | 5/8" | 0.669 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLLF93 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-20 | LYF150-20 | 3/4" | 0.827 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA0 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-10 | LYF185-10 | 3/8" | 0.413 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA1 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-12 | LYF185-12 | 1/2" | 0.512 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA2 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-16 | LYF185-16 | 5/8" | 0.669 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA3 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-20 | LYF185-20 | 3/4" | 0.827 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB0 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-10 | LYF240-10 | 3/8" | 0.413 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB1 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-12 | LYF240-12 | 1/2" | 0.512 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB2 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-16 | LYF240-16 | 5/8" | 0.669 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB3 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-20 | LYF240-20 | 3/4" | 0.827 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFLLFC0 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-10 | LYF300-10 | 3/8" | 0.413 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC1 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-12 | LYF300-12 | 1/2" | 0.512 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC2 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-16 | LYF300-16 | 5/8" | 0.669 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC3 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-20 | LYF300-20 | 3/4" | 0.827 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC4 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-24 | LYF300-24 | 15/16" | 1.024 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD0 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-12 | LYF400-12 | 1/2" | 0.512 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD1 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-16 | LYF400-16 | 5/8" | 0.669 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD2 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-20 | LYF400-20 | 3/4" | 0.827 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD3 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-24 | LYF400-24 | 15/16" | 1.024 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLLFE0 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-20 | LYF500-20 | 3/4" | 0.827 | 2.402 | 5.276 | 1.654 | 1.299 | 1.850 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLLFE1 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-24 | LYF500-24 | 15/16" | 1.024 | 2.402 | 5.276 | 1.654 | 1.299 | 1.850 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLLFF0 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-BL | LYF630-BL | 2.953 | 7.087 | 2.087 | 1.535 | 2.677 | IZUMI EP-1000A | 5 | ||
| A.W.G. 1000/1250MCM | KFLLFF1 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-20 | LYF630-20 | 3/4" | 0.827 | 2.953 | 7.087 | 2.087 | 1.535 | 2.677 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLLFF2 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-24 | LYF630-24 | 15/16" | 1.024 | 2.953 | 7.087 | 2.087 | 1.535 | 2.677 | IZUMI EP-1000A | 5 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 10mm² | KFLLF10 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-5 | LYF10-5 | 5 | 5.3 | 11.5 | 28.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLLF11 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-6 | LYF10-6 | 6 | 6.5 | 11.5 | 28.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLLF12 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-8 | LYF10-8 | 8 | 8.4 | 13.5 | 32.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLLF13 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-10 | LYF10-10 | 10 | 10.5 | 16.0 | 34.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLLF20 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-6 | LYF16-6 | 6 | 6.5 | 13.0 | 33.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 16mm² | KFLLF21 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-8 | LYF16-8 | 8 | 8.4 | 13.0 | 33.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 16mm² | KFLLF22 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-10 | LYF16-10 | 10 | 10.5 | 16.0 | 38.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 16mm² | KFLLF23 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-12 | LYF16-12 | 12 | 13.0 | 22.0 | 47.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 25mm² | KFLLF30 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-6 | LYF25-6 | 6 | 6.5 | 16.0 | 37.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 25mm² | KFLLF31 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-8 | LYF25-8 | 8 | 8.4 | 16.0 | 38.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 25mm² | KFLLF32 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-10 | LYF25-10 | 10 | 10.5 | 17.0 | 42.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 25mm² | KFLLF33 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-12 | LYF25-12 | 12 | 13.0 | 22.0 | 47.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 35mm² | KFLLF40 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-6 | LYF35-6 | 6 | 6.5 | 18.0 | 44.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 35mm² | KFLLF41 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-8 | LYF35-8 | 8 | 8.4 | 18.0 | 44.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 35mm² | KFLLF42 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-10 | LYF35-10 | 10 | 10.5 | 18.0 | 44.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 35mm² | KFLLF43 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-12 | LYF35-12 | 12 | 13.0 | 22.0 | 52.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 50mm² | KFLLF50 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-6 | LYF50-6 | 6 | 6.5 | 21.0 | 50.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLLF51 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-8 | LYF50-8 | 8 | 8.4 | 21.0 | 50.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLLF52 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-10 | LYF50-10 | 10 | 10.5 | 21.0 | 50.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLLF53 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-12 | LYF50-12 | 12 | 13.0 | 21.0 | 53.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF60 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-6 | LYF70-6 | 6 | 6.5 | 25.0 | 55.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF61 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-8 | LYF70-8 | 8 | 8.4 | 25.0 | 55.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF62 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-10 | LYF70-10 | 10 | 10.5 | 25.0 | 55.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF63 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-12 | LYF70-12 | 12 | 13.0 | 25.0 | 58.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF64 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-16 | LYF70-16 | 16 | 17.0 | 28.0 | 64.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 95mm² | KFLLF70 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-8 | LYF95-8 | 8 | 8.4 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 95mm² | KFLLF71 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-10 | LYF95-10 | 10 | 10.5 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 95mm² | KFLLF72 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-12 | LYF95-12 | 12 | 13.0 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 95mm² | KFLLF73 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-16 | LYF95-16 | 16 | 17.0 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 120mm² | KFLLF80 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-10 | LYF120-10 | 10 | 10.5 | 32.0 | 73.0 | 22.0 | 17.0 | 25.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLLF81 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-12 | LYF120-12 | 12 | 13.0 | 32.0 | 73.0 | 22.0 | 17.0 | 25.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLLF82 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-16 | LYF120-16 | 16 | 17.0 | 32.0 | 73.0 | 22.0 | 17.0 | 25.0 | IZUMI EP-520C | 30 |
| 150mm² | KFLLF90 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-10 | LYF150-10 | 10 | 10.5 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLLF91 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-12 | LYF150-12 | 12 | 13.0 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLLF92 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-16 | LYF150-16 | 16 | 17.0 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLLF93 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-20 | LYF150-20 | 20 | 21.0 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA0 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-10 | LYF185-10 | 10 | 10.5 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA1 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-12 | LYF185-12 | 12 | 13.0 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA2 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-16 | LYF185-16 | 16 | 17.0 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA3 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-20 | LYF185-20 | 20 | 21.0 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB0 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-10 | LYF240-10 | 10 | 10.5 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB1 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-12 | LYF240-12 | 12 | 13.0 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB2 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-16 | LYF240-16 | 16 | 17.0 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB3 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-20 | LYF240-20 | 20 | 21.0 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 300mm² | KFLLFC0 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-10 | LYF300-10 | 10 | 10.5 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC1 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-12 | LYF300-12 | 12 | 13.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC2 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-16 | LYF300-16 | 16 | 17.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC3 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-20 | LYF300-20 | 20 | 21.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC4 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-24 | LYF300-24 | 24 | 26.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD0 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-12 | LYF400-12 | 12 | 13.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD1 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-16 | LYF400-16 | 16 | 17.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD2 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-20 | LYF400-20 | 20 | 21.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD3 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-24 | LYF400-24 | 24 | 26.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLLFE0 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-20 | LYF500-20 | 20 | 21.0 | 61.0 | 134.0 | 42.0 | 33.0 | 47.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLLFE1 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-24 | LYF500-24 | 24 | 26.0 | 61.0 | 134.0 | 42.0 | 33.0 | 47.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLLFF0 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-BL | LYF630-BL | 75.0 | 180.0 | 53.0 | 39.0 | 68.0 | IZUMI EP-1000A | 5 | ||
| 630mm² | KFLLFF1 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-20 | LYF630-20 | 20 | 21.0 | 75.0 | 180.0 | 53.0 | 39.0 | 68.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLLFF2 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-24 | LYF630-24 | 24 | 26.0 | 75.0 | 180.0 | 53.0 | 39.0 | 68.0 | IZUMI EP-1000A | 5 |
Want to get a sample? Please fill in the form, leave your contact information and parameter information.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 8 | KFLLF10 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-5 | LYF10-5 | #10 | 0.209 | 0.453 | 1.102 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLLF11 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-6 | LYF10-6 | 1/4" | 0.256 | 0.453 | 1.102 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLLF12 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-8 | LYF10-8 | 5/16" | 0.331 | 0.531 | 1.260 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLLF13 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-10 | LYF10-10 | 3/8" | 0.413 | 0.630 | 1.339 | 0.315 | 0.197 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFLLF20 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-6 | LYF16-6 | 1/4" | 0.256 | 0.512 | 1.299 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLLF21 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-8 | LYF16-8 | 5/16" | 0.331 | 0.512 | 1.30 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLLF22 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-10 | LYF16-10 | 3/8" | 0.413 | 0.630 | 1.50 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLLF23 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-12 | LYF16-12 | 1/2" | 0.512 | 0.866 | 1.85 | 0.354 | 0.236 | 0.394 | OPT TP-150D | 500 |
| A.W.G. 4 | KFLLF30 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-6 | LYF25-6 | 1/4" | 0.256 | 0.630 | 1.457 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLLF31 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-8 | LYF25-8 | 5/16" | 0.331 | 0.630 | 1.496 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLLF32 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-10 | LYF25-10 | 3/8" | 0.413 | 0.669 | 1.654 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLLF33 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-12 | LYF25-12 | 1/2" | 0.512 | 0.866 | 1.850 | 0.433 | 0.315 | 0.433 | OPT TP-150D | 250 |
| A.W.G. 2 | KFLLF40 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-6 | LYF35-6 | 1/4" | 0.256 | 0.709 | 1.732 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLLF41 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-8 | LYF35-8 | 5/16" | 0.331 | 0.709 | 1.732 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLLF42 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-10 | LYF35-10 | 3/8" | 0.413 | 0.709 | 1.732 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLLF43 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-12 | LYF35-12 | 1/2" | 0.512 | 0.866 | 2.047 | 0.512 | 0.354 | 0.551 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFLLF50 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-6 | LYF50-6 | 1/4" | 0.256 | 0.827 | 1.969 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLLF51 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-8 | LYF50-8 | 5/16" | 0.331 | 0.827 | 1.969 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLLF52 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-10 | LYF50-10 | 3/8" | 0.413 | 0.827 | 1.969 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLLF53 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-12 | LYF50-12 | 1/2" | 0.512 | 0.827 | 2.087 | 0.571 | 0.433 | 0.669 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF60 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-6 | LYF70-6 | 1/4" | 0.256 | 0.984 | 2.165 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF61 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-8 | LYF70-8 | 5/16" | 0.331 | 0.984 | 2.17 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF62 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-10 | LYF70-10 | 3/8" | 0.413 | 0.984 | 2.17 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF63 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-12 | LYF70-12 | 1/2" | 0.512 | 0.984 | 2.28 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLLF64 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-16 | LYF70-16 | 5/8" | 0.669 | 1.102 | 2.52 | 0.669 | 0.512 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFLLF70 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-8 | LYF95-8 | 5/16" | 0.331 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLLF71 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-10 | LYF95-10 | 3/8" | 0.413 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLLF72 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-12 | LYF95-12 | 1/2" | 0.512 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLLF73 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-16 | LYF95-16 | 5/8" | 0.669 | 1.142 | 2.717 | 0.787 | 0.591 | 0.906 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFLLF80 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-10 | LYF120-10 | 3/8" | 0.413 | 1.26 | 2.874 | 0.866 | 0.669 | 0.984 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLLF81 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-12 | LYF120-12 | 1/2" | 0.512 | 1.26 | 2.874 | 0.866 | 0.669 | 0.984 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLLF82 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-16 | LYF120-16 | 5/8" | 0.669 | 1.26 | 2.874 | 0.866 | 0.669 | 0.984 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFLLF90 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-10 | LYF150-10 | 3/8" | 0.413 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLLF91 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-12 | LYF150-12 | 1/2" | 0.512 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLLF92 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-16 | LYF150-16 | 5/8" | 0.669 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLLF93 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-20 | LYF150-20 | 3/4" | 0.827 | 1.417 | 3.150 | 0.984 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA0 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-10 | LYF185-10 | 3/8" | 0.413 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA1 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-12 | LYF185-12 | 1/2" | 0.512 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA2 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-16 | LYF185-16 | 5/8" | 0.669 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLLFA3 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-20 | LYF185-20 | 3/4" | 0.827 | 1.535 | 3.386 | 1.063 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB0 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-10 | LYF240-10 | 3/8" | 0.413 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB1 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-12 | LYF240-12 | 1/2" | 0.512 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB2 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-16 | LYF240-16 | 5/8" | 0.669 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLLFB3 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-20 | LYF240-20 | 3/4" | 0.827 | 1.732 | 3.740 | 1.181 | 0.945 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFLLFC0 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-10 | LYF300-10 | 3/8" | 0.413 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC1 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-12 | LYF300-12 | 1/2" | 0.512 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC2 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-16 | LYF300-16 | 5/8" | 0.669 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC3 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-20 | LYF300-20 | 3/4" | 0.827 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLLFC4 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-24 | LYF300-24 | 15/16" | 1.024 | 1.850 | 4.488 | 1.260 | 1.024 | 1.654 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD0 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-12 | LYF400-12 | 1/2" | 0.512 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD1 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-16 | LYF400-16 | 5/8" | 0.669 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD2 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-20 | LYF400-20 | 3/4" | 0.827 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLLFD3 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-24 | LYF400-24 | 15/16" | 1.024 | 2.126 | 4.961 | 1.417 | 1.181 | 1.890 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLLFE0 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-20 | LYF500-20 | 3/4" | 0.827 | 2.402 | 5.276 | 1.654 | 1.299 | 1.850 | IZUMI EP-1000A | 5 |
| A.W.G. 800/1000MCM | KFLLFE1 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-24 | LYF500-24 | 15/16" | 1.024 | 2.402 | 5.276 | 1.654 | 1.299 | 1.850 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLLFF0 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-BL | LYF630-BL | 2.953 | 7.087 | 2.087 | 1.535 | 2.677 | IZUMI EP-1000A | 5 | ||
| A.W.G. 1000/1250MCM | KFLLFF1 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-20 | LYF630-20 | 3/4" | 0.827 | 2.953 | 7.087 | 2.087 | 1.535 | 2.677 | IZUMI EP-1000A | 5 |
| A.W.G. 1000/1250MCM | KFLLFF2 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-24 | LYF630-24 | 15/16" | 1.024 | 2.953 | 7.087 | 2.087 | 1.535 | 2.677 | IZUMI EP-1000A | 5 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 10mm² | KFLLF10 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-5 | LYF10-5 | 5 | 5.3 | 11.5 | 28.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLLF11 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-6 | LYF10-6 | 6 | 6.5 | 11.5 | 28.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLLF12 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-8 | LYF10-8 | 8 | 8.4 | 13.5 | 32.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLLF13 | 8 AWG Copper Tubular Lugs (Type LYF) LYF10-10 | LYF10-10 | 10 | 10.5 | 16.0 | 34.0 | 8.0 | 5.0 | 9.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLLF20 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-6 | LYF16-6 | 6 | 6.5 | 13.0 | 33.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 16mm² | KFLLF21 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-8 | LYF16-8 | 8 | 8.4 | 13.0 | 33.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 16mm² | KFLLF22 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-10 | LYF16-10 | 10 | 10.5 | 16.0 | 38.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 16mm² | KFLLF23 | 6 AWG Copper Tubular Lugs (Type LYF) LYF16-12 | LYF16-12 | 12 | 13.0 | 22.0 | 47.0 | 9.0 | 6.0 | 10.0 | OPT TP-150D | 500 |
| 25mm² | KFLLF30 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-6 | LYF25-6 | 6 | 6.5 | 16.0 | 37.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 25mm² | KFLLF31 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-8 | LYF25-8 | 8 | 8.4 | 16.0 | 38.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 25mm² | KFLLF32 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-10 | LYF25-10 | 10 | 10.5 | 17.0 | 42.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 25mm² | KFLLF33 | 4 AWG Copper Tubular Lugs (Type LYF) LYF25-12 | LYF25-12 | 12 | 13.0 | 22.0 | 47.0 | 11.0 | 8.0 | 11.0 | OPT TP-150D | 250 |
| 35mm² | KFLLF40 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-6 | LYF35-6 | 6 | 6.5 | 18.0 | 44.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 35mm² | KFLLF41 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-8 | LYF35-8 | 8 | 8.4 | 18.0 | 44.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 35mm² | KFLLF42 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-10 | LYF35-10 | 10 | 10.5 | 18.0 | 44.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 35mm² | KFLLF43 | 2 AWG Copper Tubular Lugs (Type LYF) LYF35-12 | LYF35-12 | 12 | 13.0 | 22.0 | 52.0 | 13.0 | 9.0 | 14.0 | OPT TP-150D | 200 |
| 50mm² | KFLLF50 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-6 | LYF50-6 | 6 | 6.5 | 21.0 | 50.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLLF51 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-8 | LYF50-8 | 8 | 8.4 | 21.0 | 50.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLLF52 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-10 | LYF50-10 | 10 | 10.5 | 21.0 | 50.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 50mm² | KFLLF53 | 1/0 AWG Copper Tubular Lugs (Type LYF) LYF50-12 | LYF50-12 | 12 | 13.0 | 21.0 | 53.0 | 14.5 | 11.0 | 17.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF60 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-6 | LYF70-6 | 6 | 6.5 | 25.0 | 55.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF61 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-8 | LYF70-8 | 8 | 8.4 | 25.0 | 55.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF62 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-10 | LYF70-10 | 10 | 10.5 | 25.0 | 55.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF63 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-12 | LYF70-12 | 12 | 13.0 | 25.0 | 58.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 70mm² | KFLLF64 | 2/0 AWG Copper Tubular Lugs (Type LYF) LYF70-16 | LYF70-16 | 16 | 17.0 | 28.0 | 64.0 | 17.0 | 13.0 | 20.0 | OPT TP-150D | 100 |
| 95mm² | KFLLF70 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-8 | LYF95-8 | 8 | 8.4 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 95mm² | KFLLF71 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-10 | LYF95-10 | 10 | 10.5 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 95mm² | KFLLF72 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-12 | LYF95-12 | 12 | 13.0 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 95mm² | KFLLF73 | 3/0 AWG Copper Tubular Lugs (Type LYF) LYF95-16 | LYF95-16 | 16 | 17.0 | 29.0 | 69.0 | 20.0 | 15.0 | 23.0 | OPT TP-150D | 50 |
| 120mm² | KFLLF80 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-10 | LYF120-10 | 10 | 10.5 | 32.0 | 73.0 | 22.0 | 17.0 | 25.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLLF81 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-12 | LYF120-12 | 12 | 13.0 | 32.0 | 73.0 | 22.0 | 17.0 | 25.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLLF82 | 4/0 AWG Copper Tubular Lugs (Type LYF) LYF120-16 | LYF120-16 | 16 | 17.0 | 32.0 | 73.0 | 22.0 | 17.0 | 25.0 | IZUMI EP-520C | 30 |
| 150mm² | KFLLF90 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-10 | LYF150-10 | 10 | 10.5 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLLF91 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-12 | LYF150-12 | 12 | 13.0 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLLF92 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-16 | LYF150-16 | 16 | 17.0 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLLF93 | 250/300MCM AWG Copper Tubular Lugs (Type LYF) LYF150-20 | LYF150-20 | 20 | 21.0 | 36.0 | 80.0 | 25.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA0 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-10 | LYF185-10 | 10 | 10.5 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA1 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-12 | LYF185-12 | 12 | 13.0 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA2 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-16 | LYF185-16 | 16 | 17.0 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLLFA3 | 300/350MCM AWG Copper Tubular Lugs (Type LYF) LYF185-20 | LYF185-20 | 20 | 21.0 | 39.0 | 86.0 | 27.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB0 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-10 | LYF240-10 | 10 | 10.5 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB1 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-12 | LYF240-12 | 12 | 13.0 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB2 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-16 | LYF240-16 | 16 | 17.0 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLLFB3 | 400MCM AWG Copper Tubular Lugs (Type LYF) LYF240-20 | LYF240-20 | 20 | 21.0 | 44.0 | 95.0 | 30.0 | 24.0 | 35.0 | IZUMI EP-520C | 10 |
| 300mm² | KFLLFC0 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-10 | LYF300-10 | 10 | 10.5 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC1 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-12 | LYF300-12 | 12 | 13.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC2 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-16 | LYF300-16 | 16 | 17.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC3 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-20 | LYF300-20 | 20 | 21.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLLFC4 | 500MCM AWG Copper Tubular Lugs (Type LYF) LYF300-24 | LYF300-24 | 24 | 26.0 | 47.0 | 114.0 | 32.0 | 26.0 | 42.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD0 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-12 | LYF400-12 | 12 | 13.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD1 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-16 | LYF400-16 | 16 | 17.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD2 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-20 | LYF400-20 | 20 | 21.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLLFD3 | 600/750MCM AWG Copper Tubular Lugs (Type LYF) LYF400-24 | LYF400-24 | 24 | 26.0 | 54.0 | 126.0 | 36.0 | 30.0 | 48.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLLFE0 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-20 | LYF500-20 | 20 | 21.0 | 61.0 | 134.0 | 42.0 | 33.0 | 47.0 | IZUMI EP-1000A | 5 |
| 500mm² | KFLLFE1 | 800/1000MCM AWG Copper Tubular Lugs (Type LYF) LYF500-24 | LYF500-24 | 24 | 26.0 | 61.0 | 134.0 | 42.0 | 33.0 | 47.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLLFF0 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-BL | LYF630-BL | 75.0 | 180.0 | 53.0 | 39.0 | 68.0 | IZUMI EP-1000A | 5 | ||
| 630mm² | KFLLFF1 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-20 | LYF630-20 | 20 | 21.0 | 75.0 | 180.0 | 53.0 | 39.0 | 68.0 | IZUMI EP-1000A | 5 |
| 630mm² | KFLLFF2 | 1000/1250MCM AWG Copper Tubular Lugs (Type LYF) LYF630-24 | LYF630-24 | 24 | 26.0 | 75.0 | 180.0 | 53.0 | 39.0 | 68.0 | IZUMI EP-1000A | 5 |
You can tick the products you need and communicate with us in the message board.
Rachel.Yue
Curry.Wang
Gavin.Peng
Lee Han
Cathy.Sun
Jackie.Li
Kageyama.Wang
Jasmine.Zhang
Allen Mo
Joan.Mo
Patrick.Delz
Xing.Chen
