Brand |
KF |
|
Finish/Coating |
Tinned |
|
Base Materials |
Copper |
|
Insulation Material |
N/A |
|
Brazed |
Seam |
|
Wire/Cable Type |
Regular Wire |
|
Color Code |
Standard |
|
MOQ |
1000Pcs/item |
|
Payment Terms |
Based on orders |
|
Delivery |
FOB/CIF/DDP |
| Spec (American AWG) | 10 | 8 | 6 | 4 | 2 | 1/0 | 2/0 | 3/0 | 4/0 | 250/300MCM | 300/350MCM | 400MCM | 500MCM | 600/750MCM |
| Spec (JIS AWG) | 6 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 | 185 | 240 | 300 | 400 |
| Spec (DIN AWG) | ||||||||||||||
| Spec (GB mm2) | ||||||||||||||
| Max Current | 50 | 70 | 95 | 125 | 170 | 230 | 265 | 310 | 360 | 445 | 505 | 545 | 620 | 785 |
You can tick the products you need and communicate with us in the message board.
| Wire Range | SKU# |
Description |
MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 10 | KFLWB10 | 10 AWG Copper Tubular Lugs (Type WB) WB6-5 | WB6-5 | #10 | 0.217 | 0.394 | 1.083 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB11 | 10 AWG Copper Tubular Lugs (Type WB) WB6-6 | WB6-6 | 1/4" | 0.256 | 0.472 | 1.08 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB12 | 10 AWG Copper Tubular Lugs (Type WB) WB6-8 | WB6-8 | 5/16" | 0.331 | 0.591 | 1.30 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB13 | 10 AWG Copper Tubular Lugs (Type WB) WB6-10 | WB6-10 | 3/8" | 0.413 | 0.669 | 1.46 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB14 | 10 AWG Copper Tubular Lugs (Type WB) WB6-12 | WB6-12 | 1/2" | 0.512 | 0.748 | 1.61 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB20 | 8 AWG Copper Tubular Lugs (Type WB) WB10-5 | WB10-5 | #10 | 0.217 | 0.472 | 1.122 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB21 | 8 AWG Copper Tubular Lugs (Type WB) WB10-6 | WB10-6 | 1/4" | 0.256 | 0.472 | 1.122 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB22 | 8 AWG Copper Tubular Lugs (Type WB) WB10-8 | WB10-8 | 5/16" | 0.331 | 0.591 | 1.378 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB23 | 8 AWG Copper Tubular Lugs (Type WB) WB10-10 | WB10-10 | 3/8" | 0.413 | 0.669 | 1.535 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB24 | 8 AWG Copper Tubular Lugs (Type WB) WB10-12 | WB10-12 | 1/2" | 0.512 | 0.748 | 1.654 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFLWB30 | 6 AWG Copper Tubular Lugs (Type WB) WB16-5 | WB16-5 | #10 | 0.217 | 0.472 | 1.240 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB31 | 6 AWG Copper Tubular Lugs (Type WB) WB16-6 | WB16-6 | 1/4" | 0.256 | 0.472 | 1.31 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB32 | 6 AWG Copper Tubular Lugs (Type WB) WB16-8 | WB16-8 | 5/16" | 0.331 | 0.591 | 1.48 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB33 | 6 AWG Copper Tubular Lugs (Type WB) WB16-10 | WB16-10 | 3/8" | 0.413 | 0.669 | 1.63 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB34 | 6 AWG Copper Tubular Lugs (Type WB) WB16-12 | WB16-12 | 1/2" | 0.512 | 0.748 | 1.77 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 4 | KFLWB40 | 4 AWG Copper Tubular Lugs (Type WB) WB25-5 | WB25-5 | #10 | 0.217 | 0.551 | 1.476 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB41 | 4 AWG Copper Tubular Lugs (Type WB) WB25-6 | WB25-6 | 1/4" | 0.256 | 0.551 | 1.476 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB42 | 4 AWG Copper Tubular Lugs (Type WB) WB25-8 | WB25-8 | 5/16" | 0.331 | 0.630 | 1.654 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB43 | 4 AWG Copper Tubular Lugs (Type WB) WB25-10 | WB25-10 | 3/8" | 0.413 | 0.709 | 1.811 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB44 | 4 AWG Copper Tubular Lugs (Type WB) WB25-12 | WB25-12 | 1/2" | 0.512 | 0.748 | 1.890 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB45 | 4 AWG Copper Tubular Lugs (Type WB) WB25-14 | WB25-14 | 9/16" | 0.591 | 0.827 | 2.067 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 2 | KFLWB50 | 2 AWG Copper Tubular Lugs (Type WB) WB35-6 | WB35-6 | 1/4" | 0.256 | 0.669 | 1.555 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB51 | 2 AWG Copper Tubular Lugs (Type WB) WB35-8 | WB35-8 | 5/16" | 0.331 | 0.669 | 1.732 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB52 | 2 AWG Copper Tubular Lugs (Type WB) WB35-10 | WB35-10 | 3/8" | 0.413 | 0.748 | 1.929 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB53 | 2 AWG Copper Tubular Lugs (Type WB) WB35-12 | WB35-12 | 1/2" | 0.512 | 0.827 | 2.008 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB54 | 2 AWG Copper Tubular Lugs (Type WB) WB35-14 | WB35-14 | 9/16" | 0.591 | 0.827 | 2.146 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB55 | 2 AWG Copper Tubular Lugs (Type WB) WB35-16 | WB35-16 | 5/8" | 0.669 | 1.024 | 2.283 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFLWB60 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-6 | WB50-6 | 1/4" | 0.256 | 0.787 | 1.850 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB61 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-8 | WB50-8 | 5/16" | 0.331 | 0.787 | 1.850 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB62 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-10 | WB50-10 | 3/8" | 0.413 | 0.787 | 2.008 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB63 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-12 | WB50-12 | 1/2" | 0.512 | 0.906 | 2.205 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB64 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-14 | WB50-14 | 9/16" | 0.591 | 0.906 | 2.343 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB65 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-16 | WB50-16 | 5/8" | 0.669 | 1.102 | 2.441 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB66 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-20 | WB50-20 | 3/4" | 0.827 | 1.181 | 2.638 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB70 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-6 | WB70-6 | 1/4" | 0.256 | 0.906 | 2.087 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB71 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-8 | WB70-8 | 5/16" | 0.331 | 0.906 | 2.09 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB72 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-10 | WB70-10 | 3/8" | 0.413 | 0.906 | 2.21 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB73 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-12 | WB70-12 | 1/2" | 0.512 | 0.906 | 2.32 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB74 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-14 | WB70-14 | 9/16" | 0.591 | 0.906 | 2.46 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB75 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-16 | WB70-16 | 5/8" | 0.669 | 1.102 | 2.60 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB76 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-20 | WB70-20 | 3/4" | 0.827 | 1.181 | 2.84 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFLWB80 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-8 | WB95-8 | 5/16" | 0.331 | 1.024 | 2.362 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB81 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-10 | WB95-10 | 3/8" | 0.413 | 1.024 | 2.362 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB82 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-12 | WB95-12 | 1/2" | 0.512 | 1.024 | 2.441 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB83 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-14 | WB95-14 | 9/16" | 0.591 | 1.024 | 2.579 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB84 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-16 | WB95-16 | 5/8" | 0.669 | 1.102 | 2.756 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB85 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-20 | WB95-20 | 3/4" | 0.827 | 1.417 | 3.228 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFLWB90 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-8 | WB120-8 | 5/16" | 0.331 | 1.102 | 2.559 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB91 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-10 | WB120-10 | 3/8" | 0.413 | 1.102 | 2.559 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB92 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-12 | WB120-12 | 1/2" | 0.512 | 1.102 | 2.559 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB93 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-14 | WB120-14 | 9/16" | 0.591 | 1.102 | 2.638 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB94 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-16 | WB120-16 | 5/8" | 0.669 | 1.181 | 2.756 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB95 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-20 | WB120-20 | 3/4" | 0.827 | 1.417 | 3.346 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFLWBA0 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-8 | WB150-8 | 5/16" | 0.331 | 1.220 | 2.756 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA1 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-10 | WB150-10 | 3/8" | 0.413 | 1.220 | 2.756 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA2 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-12 | WB150-12 | 1/2" | 0.512 | 1.220 | 2.835 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA3 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-14 | WB150-14 | 9/16" | 0.591 | 1.220 | 2.835 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA4 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-16 | WB150-16 | 5/8" | 0.669 | 1.220 | 2.913 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA5 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-20 | WB150-20 | 3/4" | 0.827 | 1.417 | 3.465 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB0 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-10 | WB185-10 | 3/8" | 0.413 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB1 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-12 | WB185-12 | 1/2" | 0.512 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB2 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-14 | WB185-14 | 9/16" | 0.591 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB3 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-16 | WB185-16 | 5/8" | 0.669 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB4 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-20 | WB185-20 | 3/4" | 0.827 | 1.535 | 3.583 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC0 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-10 | WB240-10 | 3/8" | 0.413 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC1 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-12 | WB240-12 | 1/2" | 0.512 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC2 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-14 | WB240-14 | 9/16" | 0.591 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC3 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-16 | WB240-16 | 5/8" | 0.669 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC4 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-20 | WB240-20 | 3/4" | 0.827 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFLWBD0 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-12 | WB300-12 | 1/2" | 0.512 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLWBD1 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-14 | WB300-14 | 9/16" | 0.591 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLWBD2 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-16 | WB300-16 | 5/8" | 0.669 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLWBD3 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-20 | WB300-20 | 3/4" | 0.827 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE0 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-12 | WB400-12 | 1/2" | 0.512 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE1 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-14 | WB400-14 | 9/16" | 0.591 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE2 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-16 | WB400-16 | 5/8" | 0.669 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE3 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-20 | WB400-20 | 3/4" | 0.827 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| Wire Range | SKU# |
Description |
MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 6mm² | KFLWB10 | 10 AWG Copper Tubular Lugs (Type WB) WB6-5 | WB6-5 | 5 | 5.5 | 10.0 | 27.5 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB11 | 10 AWG Copper Tubular Lugs (Type WB) WB6-6 | WB6-6 | 6 | 6.5 | 12.0 | 27.5 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB12 | 10 AWG Copper Tubular Lugs (Type WB) WB6-8 | WB6-8 | 8 | 8.4 | 15.0 | 33.0 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB13 | 10 AWG Copper Tubular Lugs (Type WB) WB6-10 | WB6-10 | 10 | 10.5 | 17.0 | 37.0 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB14 | 10 AWG Copper Tubular Lugs (Type WB) WB6-12 | WB6-12 | 12 | 13.0 | 19.0 | 41.0 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB20 | 8 AWG Copper Tubular Lugs (Type WB) WB10-5 | WB10-5 | 5 | 5.5 | 12.0 | 28.5 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB21 | 8 AWG Copper Tubular Lugs (Type WB) WB10-6 | WB10-6 | 6 | 6.5 | 12.0 | 28.5 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB22 | 8 AWG Copper Tubular Lugs (Type WB) WB10-8 | WB10-8 | 8 | 8.4 | 15.0 | 35.0 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB23 | 8 AWG Copper Tubular Lugs (Type WB) WB10-10 | WB10-10 | 10 | 10.5 | 17.0 | 39.0 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB24 | 8 AWG Copper Tubular Lugs (Type WB) WB10-12 | WB10-12 | 12 | 13.0 | 19.0 | 42.0 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLWB31 | 6 AWG Copper Tubular Lugs (Type WB) WB16-5 | WB16-5 | 5 | 5.5 | 12.0 | 31.5 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB31 | 6 AWG Copper Tubular Lugs (Type WB) WB16-6 | WB16-6 | 6 | 6.5 | 12.0 | 33.3 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB32 | 6 AWG Copper Tubular Lugs (Type WB) WB16-8 | WB16-8 | 8 | 8.4 | 15.0 | 37.5 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB33 | 6 AWG Copper Tubular Lugs (Type WB) WB16-10 | WB16-10 | 10 | 10.5 | 17.0 | 41.5 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB34 | 6 AWG Copper Tubular Lugs (Type WB) WB16-12 | WB16-12 | 12 | 13.0 | 19.0 | 45.0 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 25mm² | KFLWB40 | 4 AWG Copper Tubular Lugs (Type WB) WB25-5 | WB25-5 | 5 | 5.5 | 14.0 | 37.5 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB41 | 4 AWG Copper Tubular Lugs (Type WB) WB25-6 | WB25-6 | 6 | 6.5 | 14.0 | 37.5 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB42 | 4 AWG Copper Tubular Lugs (Type WB) WB25-8 | WB25-8 | 8 | 8.4 | 16.0 | 42.0 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB43 | 4 AWG Copper Tubular Lugs (Type WB) WB25-10 | WB25-10 | 10 | 10.5 | 18.0 | 46.0 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB44 | 4 AWG Copper Tubular Lugs (Type WB) WB25-12 | WB25-12 | 12 | 13.0 | 19.0 | 48.0 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB45 | 4 AWG Copper Tubular Lugs (Type WB) WB25-14 | WB25-14 | 14 | 15.0 | 21.0 | 52.5 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 35mm² | KFLWB50 | 2 AWG Copper Tubular Lugs (Type WB) WB35-6 | WB35-6 | 6 | 6.5 | 17.0 | 39.5 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB51 | 2 AWG Copper Tubular Lugs (Type WB) WB35-8 | WB35-8 | 8 | 8.4 | 17.0 | 44.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB52 | 2 AWG Copper Tubular Lugs (Type WB) WB35-10 | WB35-10 | 10 | 10.5 | 19.0 | 49.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB53 | 2 AWG Copper Tubular Lugs (Type WB) WB35-12 | WB35-12 | 12 | 13.0 | 21.0 | 51.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB54 | 2 AWG Copper Tubular Lugs (Type WB) WB35-14 | WB35-14 | 14 | 15.0 | 21.0 | 54.5 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB55 | 2 AWG Copper Tubular Lugs (Type WB) WB35-16 | WB35-16 | 16 | 17.0 | 26.0 | 58.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 50mm² | KFLWB60 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-6 | WB50-6 | 6 | 6.5 | 20.0 | 47.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB61 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-8 | WB50-8 | 8 | 8.4 | 20.0 | 47.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB62 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-10 | WB50-10 | 10 | 10.5 | 20.0 | 51.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB63 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-12 | WB50-12 | 12 | 13.0 | 23.0 | 56.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB64 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-14 | WB50-14 | 14 | 15.0 | 23.0 | 59.5 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB65 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-16 | WB50-16 | 16 | 17.0 | 28.0 | 62.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB66 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-20 | WB50-20 | 20 | 21.0 | 30.0 | 67.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB70 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-6 | WB70-6 | 6 | 6.5 | 23.0 | 53.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB71 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-8 | WB70-8 | 8 | 8.4 | 23.0 | 53.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB72 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-10 | WB70-10 | 10 | 10.5 | 23.0 | 56.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB73 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-12 | WB70-12 | 12 | 13.0 | 23.0 | 59.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB74 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-14 | WB70-14 | 14 | 15.0 | 23.0 | 62.5 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB75 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-16 | WB70-16 | 16 | 17.0 | 28.0 | 66.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB76 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-20 | WB70-20 | 20 | 21.0 | 30.0 | 72.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 95mm² | KFLWB80 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-8 | WB95-8 | 8 | 8.4 | 26.0 | 60.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB81 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-10 | WB95-10 | 10 | 10.5 | 26.0 | 60.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB82 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-12 | WB95-12 | 12 | 13.0 | 26.0 | 62.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB83 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-14 | WB95-14 | 14 | 15.0 | 26.0 | 65.5 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB84 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-16 | WB95-16 | 16 | 17.0 | 28.0 | 70.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB85 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-20 | WB95-20 | 20 | 21.0 | 36.0 | 82.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 120mm² | KFLWB90 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-8 | WB120-8 | 8 | 8.4 | 28.0 | 65.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB91 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-10 | WB120-10 | 10 | 10.5 | 28.0 | 65.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB92 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-12 | WB120-12 | 12 | 13.0 | 28.0 | 65.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB93 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-14 | WB120-14 | 14 | 15.0 | 28.0 | 67.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB94 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-16 | WB120-16 | 16 | 17.0 | 30.0 | 70.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB95 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-20 | WB120-20 | 20 | 21.0 | 36.0 | 85.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 150mm² | KFLWBA0 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-8 | WB150-8 | 8 | 8.4 | 31.0 | 70.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA1 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-10 | WB150-10 | 10 | 10.5 | 31.0 | 70.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA2 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-12 | WB150-12 | 12 | 13.0 | 31.0 | 72.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA3 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-14 | WB150-14 | 14 | 15.0 | 31.0 | 72.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA4 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-16 | WB150-16 | 16 | 17.0 | 31.0 | 74.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA5 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-20 | WB150-20 | 20 | 21.0 | 36.0 | 88.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB0 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-10 | WB185-10 | 10 | 10.5 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB1 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-12 | WB185-12 | 12 | 13.0 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB2 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-14 | WB185-14 | 14 | 15.0 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB3 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-16 | WB185-16 | 16 | 17.0 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB4 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-20 | WB185-20 | 20 | 21.0 | 39.0 | 91.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC0 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-10 | WB240-10 | 10 | 10.5 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC1 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-12 | WB240-12 | 12 | 13.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC2 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-14 | WB240-14 | 14 | 15.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC3 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-16 | WB240-16 | 16 | 17.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC4 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-20 | WB240-20 | 20 | 21.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 300mm² | KFLWBD0 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-12 | WB300-12 | 12 | 13.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLWBD1 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-14 | WB300-14 | 14 | 15.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLWBD2 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-16 | WB300-16 | 16 | 17.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLWBD3 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-20 | WB300-20 | 20 | 21.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE0 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-12 | WB400-12 | 12 | 13.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE1 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-14 | WB400-14 | 14 | 15.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE2 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-16 | WB400-16 | 16 | 17.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE3 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-20 | WB400-20 | 20 | 21.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
Want to get a sample? Please fill in the form, leave your contact information and parameter information.
| Wire Range | SKU# |
Description |
MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | B | L | D | d | E | ||||||
| A.W.G. 10 | KFLWB10 | 10 AWG Copper Tubular Lugs (Type WB) WB6-5 | WB6-5 | #10 | 0.217 | 0.394 | 1.083 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB11 | 10 AWG Copper Tubular Lugs (Type WB) WB6-6 | WB6-6 | 1/4" | 0.256 | 0.472 | 1.08 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB12 | 10 AWG Copper Tubular Lugs (Type WB) WB6-8 | WB6-8 | 5/16" | 0.331 | 0.591 | 1.30 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB13 | 10 AWG Copper Tubular Lugs (Type WB) WB6-10 | WB6-10 | 3/8" | 0.413 | 0.669 | 1.46 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLWB14 | 10 AWG Copper Tubular Lugs (Type WB) WB6-12 | WB6-12 | 1/2" | 0.512 | 0.748 | 1.61 | 0.256 | 0.138 | 0.354 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB20 | 8 AWG Copper Tubular Lugs (Type WB) WB10-5 | WB10-5 | #10 | 0.217 | 0.472 | 1.122 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB21 | 8 AWG Copper Tubular Lugs (Type WB) WB10-6 | WB10-6 | 1/4" | 0.256 | 0.472 | 1.122 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB22 | 8 AWG Copper Tubular Lugs (Type WB) WB10-8 | WB10-8 | 5/16" | 0.331 | 0.591 | 1.378 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB23 | 8 AWG Copper Tubular Lugs (Type WB) WB10-10 | WB10-10 | 3/8" | 0.413 | 0.669 | 1.535 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLWB24 | 8 AWG Copper Tubular Lugs (Type WB) WB10-12 | WB10-12 | 1/2" | 0.512 | 0.748 | 1.654 | 0.276 | 0.181 | 0.394 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFLWB30 | 6 AWG Copper Tubular Lugs (Type WB) WB16-5 | WB16-5 | #10 | 0.217 | 0.472 | 1.240 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB31 | 6 AWG Copper Tubular Lugs (Type WB) WB16-6 | WB16-6 | 1/4" | 0.256 | 0.472 | 1.31 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB32 | 6 AWG Copper Tubular Lugs (Type WB) WB16-8 | WB16-8 | 5/16" | 0.331 | 0.591 | 1.48 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB33 | 6 AWG Copper Tubular Lugs (Type WB) WB16-10 | WB16-10 | 3/8" | 0.413 | 0.669 | 1.63 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLWB34 | 6 AWG Copper Tubular Lugs (Type WB) WB16-12 | WB16-12 | 1/2" | 0.512 | 0.748 | 1.77 | 0.335 | 0.217 | 0.512 | OPT TP-150D | 500 |
| A.W.G. 4 | KFLWB40 | 4 AWG Copper Tubular Lugs (Type WB) WB25-5 | WB25-5 | #10 | 0.217 | 0.551 | 1.476 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB41 | 4 AWG Copper Tubular Lugs (Type WB) WB25-6 | WB25-6 | 1/4" | 0.256 | 0.551 | 1.476 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB42 | 4 AWG Copper Tubular Lugs (Type WB) WB25-8 | WB25-8 | 5/16" | 0.331 | 0.630 | 1.654 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB43 | 4 AWG Copper Tubular Lugs (Type WB) WB25-10 | WB25-10 | 3/8" | 0.413 | 0.709 | 1.811 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB44 | 4 AWG Copper Tubular Lugs (Type WB) WB25-12 | WB25-12 | 1/2" | 0.512 | 0.748 | 1.890 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLWB45 | 4 AWG Copper Tubular Lugs (Type WB) WB25-14 | WB25-14 | 9/16" | 0.591 | 0.827 | 2.067 | 0.394 | 0.276 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 2 | KFLWB50 | 2 AWG Copper Tubular Lugs (Type WB) WB35-6 | WB35-6 | 1/4" | 0.256 | 0.669 | 1.555 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB51 | 2 AWG Copper Tubular Lugs (Type WB) WB35-8 | WB35-8 | 5/16" | 0.331 | 0.669 | 1.732 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB52 | 2 AWG Copper Tubular Lugs (Type WB) WB35-10 | WB35-10 | 3/8" | 0.413 | 0.748 | 1.929 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB53 | 2 AWG Copper Tubular Lugs (Type WB) WB35-12 | WB35-12 | 1/2" | 0.512 | 0.827 | 2.008 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB54 | 2 AWG Copper Tubular Lugs (Type WB) WB35-14 | WB35-14 | 9/16" | 0.591 | 0.827 | 2.146 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLWB55 | 2 AWG Copper Tubular Lugs (Type WB) WB35-16 | WB35-16 | 5/8" | 0.669 | 1.024 | 2.283 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFLWB60 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-6 | WB50-6 | 1/4" | 0.256 | 0.787 | 1.850 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB61 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-8 | WB50-8 | 5/16" | 0.331 | 0.787 | 1.850 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB62 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-10 | WB50-10 | 3/8" | 0.413 | 0.787 | 2.008 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB63 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-12 | WB50-12 | 1/2" | 0.512 | 0.906 | 2.205 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB64 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-14 | WB50-14 | 9/16" | 0.591 | 0.906 | 2.343 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB65 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-16 | WB50-16 | 5/8" | 0.669 | 1.102 | 2.441 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLWB66 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-20 | WB50-20 | 3/4" | 0.827 | 1.181 | 2.638 | 0.551 | 0.394 | 0.748 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB70 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-6 | WB70-6 | 1/4" | 0.256 | 0.906 | 2.087 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB71 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-8 | WB70-8 | 5/16" | 0.331 | 0.906 | 2.09 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB72 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-10 | WB70-10 | 3/8" | 0.413 | 0.906 | 2.21 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB73 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-12 | WB70-12 | 1/2" | 0.512 | 0.906 | 2.32 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB74 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-14 | WB70-14 | 9/16" | 0.591 | 0.906 | 2.46 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB75 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-16 | WB70-16 | 5/8" | 0.669 | 1.102 | 2.60 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLWB76 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-20 | WB70-20 | 3/4" | 0.827 | 1.181 | 2.84 | 0.650 | 0.472 | 0.827 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFLWB80 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-8 | WB95-8 | 5/16" | 0.331 | 1.024 | 2.362 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB81 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-10 | WB95-10 | 3/8" | 0.413 | 1.024 | 2.362 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB82 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-12 | WB95-12 | 1/2" | 0.512 | 1.024 | 2.441 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB83 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-14 | WB95-14 | 9/16" | 0.591 | 1.024 | 2.579 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB84 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-16 | WB95-16 | 5/8" | 0.669 | 1.102 | 2.756 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLWB85 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-20 | WB95-20 | 3/4" | 0.827 | 1.417 | 3.228 | 0.709 | 0.531 | 0.984 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFLWB90 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-8 | WB120-8 | 5/16" | 0.331 | 1.102 | 2.559 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB91 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-10 | WB120-10 | 3/8" | 0.413 | 1.102 | 2.559 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB92 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-12 | WB120-12 | 1/2" | 0.512 | 1.102 | 2.559 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB93 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-14 | WB120-14 | 9/16" | 0.591 | 1.102 | 2.638 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB94 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-16 | WB120-16 | 5/8" | 0.669 | 1.181 | 2.756 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLWB95 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-20 | WB120-20 | 3/4" | 0.827 | 1.417 | 3.346 | 0.768 | 0.591 | 1.024 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFLWBA0 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-8 | WB150-8 | 5/16" | 0.331 | 1.220 | 2.756 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA1 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-10 | WB150-10 | 3/8" | 0.413 | 1.220 | 2.756 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA2 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-12 | WB150-12 | 1/2" | 0.512 | 1.220 | 2.835 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA3 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-14 | WB150-14 | 9/16" | 0.591 | 1.220 | 2.835 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA4 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-16 | WB150-16 | 5/8" | 0.669 | 1.220 | 2.913 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLWBA5 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-20 | WB150-20 | 3/4" | 0.827 | 1.417 | 3.465 | 0.827 | 0.650 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB0 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-10 | WB185-10 | 3/8" | 0.413 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB1 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-12 | WB185-12 | 1/2" | 0.512 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB2 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-14 | WB185-14 | 9/16" | 0.591 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB3 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-16 | WB185-16 | 5/8" | 0.669 | 1.378 | 3.268 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLWBB4 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-20 | WB185-20 | 3/4" | 0.827 | 1.535 | 3.583 | 0.945 | 0.748 | 1.181 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC0 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-10 | WB240-10 | 3/8" | 0.413 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC1 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-12 | WB240-12 | 1/2" | 0.512 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC2 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-14 | WB240-14 | 9/16" | 0.591 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC3 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-16 | WB240-16 | 5/8" | 0.669 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLWBC4 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-20 | WB240-20 | 3/4" | 0.827 | 1.535 | 3.681 | 1.024 | 0.827 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFLWBD0 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-12 | WB300-12 | 1/2" | 0.512 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLWBD1 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-14 | WB300-14 | 9/16" | 0.591 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLWBD2 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-16 | WB300-16 | 5/8" | 0.669 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLWBD3 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-20 | WB300-20 | 3/4" | 0.827 | 1.693 | 4.370 | 1.161 | 0.925 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE0 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-12 | WB400-12 | 1/2" | 0.512 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE1 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-14 | WB400-14 | 9/16" | 0.591 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE2 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-16 | WB400-16 | 5/8" | 0.669 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLWBE3 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-20 | WB400-20 | 3/4" | 0.827 | 1.929 | 4.488 | 1.339 | 1.063 | 1.732 | IZUMI EP-1000A | 5 |
| Wire Range | SKU# |
Description |
MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | B | L | D | d | E | ||||||
| 6mm² | KFLWB10 | 10 AWG Copper Tubular Lugs (Type WB) WB6-5 | WB6-5 | 5 | 5.5 | 10.0 | 27.5 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB11 | 10 AWG Copper Tubular Lugs (Type WB) WB6-6 | WB6-6 | 6 | 6.5 | 12.0 | 27.5 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB12 | 10 AWG Copper Tubular Lugs (Type WB) WB6-8 | WB6-8 | 8 | 8.4 | 15.0 | 33.0 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB13 | 10 AWG Copper Tubular Lugs (Type WB) WB6-10 | WB6-10 | 10 | 10.5 | 17.0 | 37.0 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLWB14 | 10 AWG Copper Tubular Lugs (Type WB) WB6-12 | WB6-12 | 12 | 13.0 | 19.0 | 41.0 | 6.5 | 3.5 | 9.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB20 | 8 AWG Copper Tubular Lugs (Type WB) WB10-5 | WB10-5 | 5 | 5.5 | 12.0 | 28.5 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB21 | 8 AWG Copper Tubular Lugs (Type WB) WB10-6 | WB10-6 | 6 | 6.5 | 12.0 | 28.5 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB22 | 8 AWG Copper Tubular Lugs (Type WB) WB10-8 | WB10-8 | 8 | 8.4 | 15.0 | 35.0 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB23 | 8 AWG Copper Tubular Lugs (Type WB) WB10-10 | WB10-10 | 10 | 10.5 | 17.0 | 39.0 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLWB24 | 8 AWG Copper Tubular Lugs (Type WB) WB10-12 | WB10-12 | 12 | 13.0 | 19.0 | 42.0 | 7.0 | 4.6 | 10.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLWB31 | 6 AWG Copper Tubular Lugs (Type WB) WB16-5 | WB16-5 | 5 | 5.5 | 12.0 | 31.5 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB31 | 6 AWG Copper Tubular Lugs (Type WB) WB16-6 | WB16-6 | 6 | 6.5 | 12.0 | 33.3 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB32 | 6 AWG Copper Tubular Lugs (Type WB) WB16-8 | WB16-8 | 8 | 8.4 | 15.0 | 37.5 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB33 | 6 AWG Copper Tubular Lugs (Type WB) WB16-10 | WB16-10 | 10 | 10.5 | 17.0 | 41.5 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 16mm² | KFLWB34 | 6 AWG Copper Tubular Lugs (Type WB) WB16-12 | WB16-12 | 12 | 13.0 | 19.0 | 45.0 | 8.5 | 5.5 | 13.0 | OPT TP-150D | 500 |
| 25mm² | KFLWB40 | 4 AWG Copper Tubular Lugs (Type WB) WB25-5 | WB25-5 | 5 | 5.5 | 14.0 | 37.5 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB41 | 4 AWG Copper Tubular Lugs (Type WB) WB25-6 | WB25-6 | 6 | 6.5 | 14.0 | 37.5 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB42 | 4 AWG Copper Tubular Lugs (Type WB) WB25-8 | WB25-8 | 8 | 8.4 | 16.0 | 42.0 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB43 | 4 AWG Copper Tubular Lugs (Type WB) WB25-10 | WB25-10 | 10 | 10.5 | 18.0 | 46.0 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB44 | 4 AWG Copper Tubular Lugs (Type WB) WB25-12 | WB25-12 | 12 | 13.0 | 19.0 | 48.0 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLWB45 | 4 AWG Copper Tubular Lugs (Type WB) WB25-14 | WB25-14 | 14 | 15.0 | 21.0 | 52.5 | 10.0 | 7.0 | 15.0 | OPT TP-150D | 250 |
| 35mm² | KFLWB50 | 2 AWG Copper Tubular Lugs (Type WB) WB35-6 | WB35-6 | 6 | 6.5 | 17.0 | 39.5 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB51 | 2 AWG Copper Tubular Lugs (Type WB) WB35-8 | WB35-8 | 8 | 8.4 | 17.0 | 44.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB52 | 2 AWG Copper Tubular Lugs (Type WB) WB35-10 | WB35-10 | 10 | 10.5 | 19.0 | 49.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB53 | 2 AWG Copper Tubular Lugs (Type WB) WB35-12 | WB35-12 | 12 | 13.0 | 21.0 | 51.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB54 | 2 AWG Copper Tubular Lugs (Type WB) WB35-14 | WB35-14 | 14 | 15.0 | 21.0 | 54.5 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLWB55 | 2 AWG Copper Tubular Lugs (Type WB) WB35-16 | WB35-16 | 16 | 17.0 | 26.0 | 58.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 50mm² | KFLWB60 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-6 | WB50-6 | 6 | 6.5 | 20.0 | 47.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB61 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-8 | WB50-8 | 8 | 8.4 | 20.0 | 47.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB62 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-10 | WB50-10 | 10 | 10.5 | 20.0 | 51.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB63 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-12 | WB50-12 | 12 | 13.0 | 23.0 | 56.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB64 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-14 | WB50-14 | 14 | 15.0 | 23.0 | 59.5 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB65 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-16 | WB50-16 | 16 | 17.0 | 28.0 | 62.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 50mm² | KFLWB66 | 1/0 AWG Copper Tubular Lugs (Type WB) WB50-20 | WB50-20 | 20 | 21.0 | 30.0 | 67.0 | 14.0 | 10.0 | 19.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB70 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-6 | WB70-6 | 6 | 6.5 | 23.0 | 53.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB71 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-8 | WB70-8 | 8 | 8.4 | 23.0 | 53.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB72 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-10 | WB70-10 | 10 | 10.5 | 23.0 | 56.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB73 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-12 | WB70-12 | 12 | 13.0 | 23.0 | 59.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB74 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-14 | WB70-14 | 14 | 15.0 | 23.0 | 62.5 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB75 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-16 | WB70-16 | 16 | 17.0 | 28.0 | 66.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 70mm² | KFLWB76 | 2/0 AWG Copper Tubular Lugs (Type WB) WB70-20 | WB70-20 | 20 | 21.0 | 30.0 | 72.0 | 16.5 | 12.0 | 21.0 | OPT TP-150D | 100 |
| 95mm² | KFLWB80 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-8 | WB95-8 | 8 | 8.4 | 26.0 | 60.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB81 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-10 | WB95-10 | 10 | 10.5 | 26.0 | 60.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB82 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-12 | WB95-12 | 12 | 13.0 | 26.0 | 62.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB83 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-14 | WB95-14 | 14 | 15.0 | 26.0 | 65.5 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB84 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-16 | WB95-16 | 16 | 17.0 | 28.0 | 70.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 95mm² | KFLWB85 | 3/0 AWG Copper Tubular Lugs (Type WB) WB95-20 | WB95-20 | 20 | 21.0 | 36.0 | 82.0 | 18.0 | 13.5 | 25.0 | OPT TP-150D | 50 |
| 120mm² | KFLWB90 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-8 | WB120-8 | 8 | 8.4 | 28.0 | 65.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB91 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-10 | WB120-10 | 10 | 10.5 | 28.0 | 65.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB92 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-12 | WB120-12 | 12 | 13.0 | 28.0 | 65.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB93 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-14 | WB120-14 | 14 | 15.0 | 28.0 | 67.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB94 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-16 | WB120-16 | 16 | 17.0 | 30.0 | 70.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLWB95 | 4/0 AWG Copper Tubular Lugs (Type WB) WB120-20 | WB120-20 | 20 | 21.0 | 36.0 | 85.0 | 19.5 | 15.0 | 26.0 | IZUMI EP-520C | 30 |
| 150mm² | KFLWBA0 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-8 | WB150-8 | 8 | 8.4 | 31.0 | 70.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA1 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-10 | WB150-10 | 10 | 10.5 | 31.0 | 70.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA2 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-12 | WB150-12 | 12 | 13.0 | 31.0 | 72.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA3 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-14 | WB150-14 | 14 | 15.0 | 31.0 | 72.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA4 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-16 | WB150-16 | 16 | 17.0 | 31.0 | 74.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLWBA5 | 250/300MCM AWG Copper Tubular Lugs (Type WB) WB150-20 | WB150-20 | 20 | 21.0 | 36.0 | 88.0 | 21.0 | 16.5 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB0 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-10 | WB185-10 | 10 | 10.5 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB1 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-12 | WB185-12 | 12 | 13.0 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB2 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-14 | WB185-14 | 14 | 15.0 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB3 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-16 | WB185-16 | 16 | 17.0 | 35.0 | 83.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLWBB4 | 300/350MCM AWG Copper Tubular Lugs (Type WB) WB185-20 | WB185-20 | 20 | 21.0 | 39.0 | 91.0 | 24.0 | 19.0 | 30.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC0 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-10 | WB240-10 | 10 | 10.5 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC1 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-12 | WB240-12 | 12 | 13.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC2 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-14 | WB240-14 | 14 | 15.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC3 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-16 | WB240-16 | 16 | 17.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLWBC4 | 400MCM AWG Copper Tubular Lugs (Type WB) WB240-20 | WB240-20 | 20 | 21.0 | 39.0 | 93.5 | 26.0 | 21.0 | 35.0 | IZUMI EP-520C | 10 |
| 300mm² | KFLWBD0 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-12 | WB300-12 | 12 | 13.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLWBD1 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-14 | WB300-14 | 14 | 15.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLWBD2 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-16 | WB300-16 | 16 | 17.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLWBD3 | 500MCM AWG Copper Tubular Lugs (Type WB) WB300-20 | WB300-20 | 20 | 21.0 | 43.0 | 111.0 | 29.5 | 23.5 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE0 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-12 | WB400-12 | 12 | 13.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE1 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-14 | WB400-14 | 14 | 15.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE2 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-16 | WB400-16 | 16 | 17.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLWBE3 | 600/750MCM AWG Copper Tubular Lugs (Type WB) WB400-20 | WB400-20 | 20 | 21.0 | 49.0 | 114.0 | 34.0 | 27.0 | 44.0 | IZUMI EP-1000A | 5 |
You can tick the products you need and communicate with us in the message board.
Rachel.Yue
Curry.Wang
Gavin.Peng
Lee Han
Cathy.Sun
Jackie.Li
Kageyama.Wang
Jasmine.Zhang
Allen Mo
Joan.Mo
Patrick.Delz
Xing.Chen
